Trumpf TruSystem 7000 Service Manual page 179

Mat. no. Cable
1726987 Cable adapter
(Option A)
1949603
(Option B)
Table base
1662803 W150
1663044 W151
1663047 W152
1663074 W153
1663075 W154
1663076 W155
1725425 W177
1700850 W156
1700852 W158
1700851 W157
1642436 W175
1735554 W162
1717944 Ground wire _25
*1
not available on all operating table versions.
Service Manual TruSystem 7000 Operating Table – 1 764 986 – 10/2016
Cable routing
*1
Cable from the ISM module to the motor
controller
Cable from the coupling point (plug
connection) in the table base to the line
power socket
Cable from the coupling point (plug
connection) in the table base, via the filter to
the control module
Cable from the coupling point (plug
connection) in the table base to the filter
Cable from the button to the control module Chapter 22.4,
Cable from the fuse holder to the button
Cable from the coupling point (plug
connection) in the table base to the fuse
holder and the button
Cable from the filter to the control module Chapter 22.7,
Cable from the assembly to the control
module
Cable from the assembly to the control
module
Cable from the sensor on the 5th wheel to
the control module
Cable from the small filter (1 A) to the large
filter (12 A)
Ground wire from the line power socket to
the column base
Cabling overview
Description
Chapter 21.15,
page 230
Chapter 22.1,
page 233
Chapter 22.2,
page 236
Chapter 22.3,
page 238
page 240
Chapter 22.5,
page 242
Chapter 22.6,
page 244
page 247
Chapter 22.8,
page 249
Chapter 22.9,
page 251
Chapter 22.10,
page 253
Chapter 22.11,
page 256
Chapter 22.12,
page 258
