Bleeding the hydraulic system
162
button because there is still too little pressure in the system. The
system is bled when the floor locks extend fully (25 mm / 35
mm). The air is pulled into the oil container and maximum
pressure builds during locking.
Make sure the floor locks retract after the procedure
(necessary to right the table).
9. Install the two upper locking cylinders.
10. Restore the original cable routing. Check all connections on
the jack unit to be sure they are secure.
Carefully insert the cover with the assembly into the table base
and mount it (4 screws with washers).
11. Safety note: The operating table is extremely heavy; take extra
care not to strain your back while righting it. A second person
is needed to right the operating table. Clear the floor in front
of the operating table and clean it if necessary. Right the
operating table with the help of a second person.
12. Replace the label over the E
13. Remove the multifunction tool.
14. Remove the toothed wheel.
15. Lock operating table (brake)
16. Put on the pad.
TEST
Perform function test and final check.
Service Manual TruSystem 7000 Operating Table – 1 764 986 – 10/2016
button.
MERGENCY RELEASE
