Summary of Contents for Modern Forms Torque
- Page 1 Torque Installation Instructions works with the Google Assistant...
- Page 2 Please read and save these instructions before installation DO NOT RETURN TO STORE Torque Instructions FR-W2204-58...
- Page 3 For fast service have the following information below when you call: Model Name and Number 2. Part Number and Part Description 3. Date Of Purchase and Purchase Location 1-866-810-6615 option 1 MON-FRI 8AM-8PM EST Email: fansupport@modernforms.com Torque Instructions 3 FR-W2204-58...
- Page 4 The wires should be spread apart with the grounded conductor and the equipment-grounding conductor on one side of the outlet box, and the ungrounded conductor on the other side of the outlet box. All set screws must be checked and re-tightened where necessary before installation. Torque Instructions FR-W2204-58...
- Page 5 Modern Forms. Substitution of parts or accessories not designated for use with this product by Modern Forms could result in personal injury or property damage and will void the warranty. Contact an authorized dealer or the manufacturer if any parts are damaged or missing.
- Page 6 Wi-Fi and Bluetooth enabled features: complement high quality materials Quiet, reliable, and up to 70% MOTOR Bluetooth Remote Control 6 fan speeds F-RCBT-WT White Accessories: Bluetooth Wall Control 6 fan speeds | Sold separately personalize your experience F-WCBT-WT White Torque Instructions FR-W2204-58...
-
Page 7: Table Of Contents
4. Hanging the Fan 5. Making the Electrical Connections 6. Installing the Optional Wall Control 7. Finishing the Installation 8. Controlling the Fan 9. Reset 10. Breeze Mode 11 . Application 12. Accessories 13. Troubleshooting 28-31 Tools Required Torque Instructions 7 FR-W2204-58... - Page 8 To order replacement hex screws/wrench - order part no. RPL-F2204-HEX-** efore discarding packaging materials be certain all parts have been removed. Place the parts from the hardware bag into a small container to keep them from being lost. Torque Instructions FR-W2204-58L...
- Page 9 Hanging Weight: 19 lbs IMPORTANT: Please make note of the MAC ID on the receiver and keep it in a safe place. Torque Instructions 9 FR-W2204-58...
-
Page 10: Mounting Options
The sloped ceiling kit (sold separately) is required for sloped ceiling applications, and will accommodate slopes up to 45° (Fig. 1B). NOTE: You may need a longer downrod to maintain proper blade clearance when installing on a steep, sloped ceiling (Fig. 1B). Torque Instructions FR-W2204-58L... - Page 11 Support Brace 2. Outlet Box 3. Joist Outlet Box Support Ceiling Max 30° Angle Support Brace 2. Mounting Bracket 3. Recess Outlet Box Outlet Box Torque Instructions 11 FR-W2204-58L...
-
Page 12: Installing The Mounting Bracket
Twist the bottom cap onto the bottom of the fan as shown. (Fig. 3B) NOTE: You may want to place the fan housing on the included styrofoam to help stabilize the housing during the blade installation process. Torque Instructions FR-W2204-58L... - Page 13 120V Wires 2. cUL Listed Electrical Box Mounting Bracket 3. Mounting Bracket 2. Screw 4. Mounting Screws (supplied with outlet box) Torque Instructions 13 FR-W2204-58L...
-
Page 14: Hanging The Fan
Refer to Part C NOTE: A Safety cable is required for all installations in Canada. Safety cable is required for ceiling fan and light combinations over 35 lbs. in both flush and downrod models in the United States. Torque Instructions FR-W2204-58L... - Page 15 Torque Instructions 15 FR-W2204-58L...
-
Page 16: Making The Electrical Connections
3. Connect the grey wire from the fan to the grey wire marked “TO MOTOR” from the receiver. 4. Connect the yellow wire from the fan to the yellow wire marked “ TO MOTOR ” from the receiver. Torque Instructions FR-W2204-58L... - Page 17 Follow the steps above to connect the fan to your household wiring. Use the plastic wire nuts with your fan. Secure the plastic wire nuts with electrical tape. Make sure there are no loose strands or connections. Torque Instructions 17 FR-W2204-58L...
-
Page 18: Installing The Optional Wall Control
Fasten the wall plate to the wall mounting plate (Fig. 6A). to Fan House Wires Wall Switch Wires (Hot) (Hot In) (Neutral) (Neutral) (Copper/Ground) (Ground) Fan Switch leg (Hot out to Fan) From Breaker * Home Wiring may vary Torque Instructions FR-W2204-58L... - Page 19 Individually pair each of the wall controls with the fan receiver using the pairing instruction. See page 27. If Applicable Wallcontroller 1 Wallcontroller 2 Wallcontroller 3 Wall Control 3 Wall Control 1 Wall Control 2 Line/Hot Green (Green or Bare) Neutral/White Torque Instructions 19 FR-W2204-58L...
-
Page 20: Finishing The Installation
(Fig. 7A) WARNING: Make sure tab at bottom of hanger bracket is properly seated in groove of hanger ball before attaching canopy to bracket. Failure to properly seat tab in groove could cause damage to electrical wiring. Torque Instructions FR-W2204-58L... - Page 21 Torque Instructions 21 FR-W2204-58L...
-
Page 22: Controlling The Fan
NOTE: Pairing must be completed within three (3) minutes of powering the fan. Synchronizing Control Across Multiple Fans If you are controlling multiple fans with one controller, fans/lights may be synced by referring to Fig. 8B and instructions on the next page. Torque Instructions FR-W2204-58L... - Page 23 All fans will be set to summer mode (CCW rotation). This will bring all fans controlled by the remote into sync. Torque Instructions 23 FR-W2204-58L...
-
Page 24: Reset
In addition to the included remote control, you can control your fan with a wall control (sold separately) or through the Modern Forms app. To use the Modern Forms app, download it for free from the App Store or Google Play. - Page 25 Press the reset button on the receiver until the fan emits 3 beeps indicating the reset receiver emits 3 beeps indicating the reset Scan and follow prompts for multilingual instruction options and Smart Fan FAQs: For detailed Instructions and Smart Home Device Integration Torque Instructions 25 FR-W2204-58L...
-
Page 26: Accessories
12. Accessories personalize your experience Bluetooth Wall Control Dims light to 1% | ON/OFF 6 fan speeds | Sold separately F-WCBT-WT White Bluetooth Remote Control Dims light to 1% | ON/OFF 6 fan speeds F-RCBT-WT White Torque Instructions FR-W2204-58L... - Page 27 Connects two downrods XF-I Downrod XF-12 - 12” Downrod | XF-18 - 18” Downrod XF-24 - 24” Downrod | XF-36 - 36” Downrod XF-48 - 48” Downrod | XF-60 - 60” Downrod XF-72 - 72” Downrod Torque Instructions 27 FR-W2204-58L...
-
Page 28: Troubleshooting
4. Make sure the fan blades are properly aligned and securely fastened to the motor housing assembly/blade arms. 5. Make sure the gaps between the blades are evenly distributed or make sure you are using an approved cUL/UL listed outlet box and it is installed correctly. Torque Instructions FR-W2204-58L... - Page 29 Your fan supports connection with 2.4GHz 802.11b/g/n networks. Confirm your network is compatible by checking your router settings or contact your router manufacturer. 2. Make sure your network’s SSID is not hidden. 3. Your fan does not support 5 GHz network connectivity.connection. Torque Instructions 29 FR-W2204-58L...
- Page 30 10 seconds and back on. If your fan is wired through a Modern Forms wall control (P/N: F-WCBT- WT) pull the Air-Gap Switch on your wall control, wait 10 seconds, and re-insert.
- Page 31 What is Pairing? Pairing is the process of connecting your Modern Forms remote or wall control to your fan. Your fan comes pre-paired to your included remote control. However, if you want additional controls for your fan or if you’re replacing a control, refer to the pairing and unpairing section of the instructions.
- Page 32 Notice of a defect in writing must be received by Modern Forms within five (5) years from the date of purchase (or according period of time as outlined by material). Excluded from warranty are any 3rd party component which carries its own manufacturer’s warranty.
- Page 33 La notificación de un defecto por escrito debe ser recibida por Modern Forms dentro de los cinco (5) años a partir de la fecha de compra (o según el período de tiempo indicado en el material). Quedan excluidos de la garantía todos los componentes de terceros que tengan la garantía de su propio fabricante.
- Page 34 Torque Instructions FR-W2204-58L...
- Page 35 Torque Instructions 37 FR-W2204-58L...
- Page 36 FR-W220 4- 58 modernforms.com...
