Neu-X101 Quick Reference Guide

M2M

Pin Function Pin
01 GND 18
02 +3VSB 19
03 GND 20
04 +3VSB 21
05 NC 22
1
06 NC 23
07 NC 24
08 NC 25
09 GND 26
10 M2M_LED# 27
11 NC 28
74 12 +3VSB 29
75
13 NC 30
14 +3VSB 31
15 GND 32
16 +3VSB 33
17 NC 34
Quick reference guide is subject to change without prior notice. For any update,
please visit our website: www.nexcom.com
=Pin1 [ * ]=Default setting
Function Pin Function Pin
+3VSB 35 NC 52
NC 36 NC 53
NC 37 NC 54
GND 38 DEVSLP 55
NC 39 GND 56
NC 40 NC 57
NC 41 SATA_RXP 58
NC 42 NC 67
NC 43 SATA_RXN 68
GND 44 NC 69
NC 45 GND 70
NC 46 NC 71
NC 47 SATA_TXN 72
NC 48 NC 73
NC 49 SATA_TXP 74
GND 50 RESET# 75
NC 51 GND
Function
NC
NC
NC
NC
NC
GND
NC
NC
NC
NC
+3VSB
GND
+3VSB
GND
+3VSB
GND
