SCHATTELLO Mounting Instructions:
Exchanging the canopy
Warning
Thank you for purchasing a MAY spare canopy
This instruction manual includes all necessary information on how to attach your MAY spare canopy onto a
MAY parasol frame. Read these instructions carefully to guarantee a save assembly.
Stand 42-2224
Non-observation of mounting instructions can result in personal injuries or
damage to property.
Please note that if these instructions are not observed, the manufacturer cannot
assume any liability or guarantee.
• Always follow the safety regulations.
• Should you not understand any part of these mounting instructions, please
contact your MAY dealer.
Deutsch / English / Français
SCHATTELLO
page 1 of 20
Advertisement
Related Manuals for MAY SCHATTELLO
Summary of Contents for MAY SCHATTELLO
- Page 1 MAY dealer. Thank you for purchasing a MAY spare canopy This instruction manual includes all necessary information on how to attach your MAY spare canopy onto a MAY parasol frame. Read these instructions carefully to guarantee a save assembly.
-
Page 2: Table Of Contents
Content Page 03 Cleaning the canopy Page 04 Repairing the holes Page 07 Removing the canopy Page 11 Unpacking the canopy Page 11 Attaching the canopy Seite 2 of 20 Deutsch / English / Français Stand 42-2224... -
Page 3: Cleaning The Canopy
• Distance from nozzle to fabric minimum 30 cm. 3. After cleaning set the temperature on “cold” and spray as long there is no visible foam (you may have to remove the cleanser from the high-pressure cleaner). 4. Let the parasol get dry in open position to avoid crinkling. -
Page 4: Repairing The Holes
MAY label. MAY label • By indicating the serial number (see serial plate at the centre pole), your MAY consultant can identify the fabric number accordingly. • Photos are not true to colour and therefore are not recommended. - Page 5 • MayTex-PVC, article no. 352869 + indicate colour number 4. Get the fabric glue. You can order the suitable textile glue for the original canopies at the MAY company. A tube contains 30 g and is adequate for several DIN-A4 patches.
- Page 6 9. Apply the textile glue evenly all over the patch. Follow the specifi- cations of the glue manufacturer. 10. Step onto the ladder and glue the patch centered onto the hole or slit. There must not leak any glue from the patch.
-
Page 7: Removing The Canopy
Removing the canopy Wind can turn a loose canopy into a sail. If wind blows into an unsecured canopy, it may fly away with enormous power. This may cause personal injury or material damage to the frame or surrounding Danger obstacles. - Page 8 5. Push the telescopic tube towards the centre pole. When using the optional assembly aid by MAY the force is distributed evenly on the palm which facilitates the assembly. • Assembly aid SCHATTELLO article no. 357816 • Assembly aid ALBATROS article no.
- Page 9 9. Reach over the canopy (to the top) and remove the head plate by turning it clockwise. Inappropriate use of a ladder can cause personal injury and material damage. If a ladder is positioned insecure or laid-out too weak, you may fall off the ladder.
- Page 10 10. Remove the hooks Hook 11. A parasol frame without canopy can be cleaned optimally. With water and soap CleanoMay 13 article no. 350848 dirt can easily be washed off the aluminium profiles. With a bit of time, you will gain a fresh and clean appearance.
-
Page 11: Unpacking The Canopy
• Do not use a knife or any sharp object to remove the packaging. Caution 2. Take the canopy out of the box. Putting the canopy down to the floor may damage the canopy or it may get dirty. Also, the own weight may cause cuts or abrasions. Danger •... - Page 12 2. Use a free standing-ladder for assembly (double ladder). Inappropriate use of a ladder can cause personal injury and material damage. If a ladder is positioned insecure or laid-out too weak, you may fall off the ladder. Danger • Use a free-standing ladder (double ladder).
- Page 13 Prevent this by taking one of the following precautions: • Put a “plastic end cap“ onto each nut. You can use regular M10, commercially available or you order them at the MAY company. See list “spare parts: type SCHATTELLO“, e.g. in white, article no. 353969.
- Page 14 7. Use a free-standing ladder to put the canopy cantered on top of the parasol frame. 8. Spread the canopy. Top and bottom side differ in the hook position. The hooks are sewed to the bottom part. 9. There is an opening in the centre of the canopy, put it at this point over the parasol frame. 10.
- Page 15 11. Only for square and rectangular parasols, position of MAY label: If several parasols are positioned in a row, it looks better when all labels are positioned equally. Position the label always at the diagonal spoke (A1) directly besides the crank.
- Page 16 (with assembly aid, optional tool) and pull the hook outwards until it can be hooked in. Telescopic shaft The canopy may get damaged. Unless each hook is attached, the wind load cannot be absorbed properly. This leads to premature wear and tear.
- Page 17 15. Attach the end cap. Pay attention, the cap fits only in a certain position, you may have to turn it. Until year 2017 a connector system was assembled, these can be impressed with relatively low effort. End cap 16. As of the year 2018, the end cap has been screwed on, therefore a screwdriver Torx 15 is required.
- Page 18 17. In case you have a canopy with hook and loop fastener, wrap and connect them around the spokes. Seite 18 of 20 Deutsch / English / Français Stand 42-2224...
- Page 19 Stand 42-2224 Deutsch / English / Français page 19 of 20...
- Page 20 Seite 20 of 20 Deutsch / English / Français Stand 42-2224...
