Printer
The parameter which configures the type of printer connected to the
selected CMDN display. For an FCC type environment, the printer
option is not available on the lowest (first) and highest (last)
CMDN/SMDN network addresses, as the RS-232 port is used for
network communications. Printer options can be directly entered using
the letters "N," "F," & "S," i.e. valid options are: {None}, Form, &
Strip.
Project Description
An identification label for this file. The project name may be up to 20
characters in length.
Project Name
The DOS filename under which the CMDN configuration information
is saved. The project filename may contain up to eight (8) characters.
The following characters are not valid in filenames: * ? , ; [ ] + = \ / : |
< >. The IRC-3 option requires the use of a unique filename for each
CMDN used.
Routing
A filter which defines whether all messages meeting the Annunciation
Type criteria (above) are displayed or only messages meeting the
Annunciation Type criteria and are defined in the selected CMDN's
memory are displayed. When all messages is selected and no message
is defined in the selected CMDN's memory, the display will indicate:
No Definition Found.
Select FCC Text
See FCC Text.
Selected Display
The parameter which selects the address of the CMDN/SMDN actively
being configured.
Set to No Switch Panel
A command to configure an annunciator without front panel switches
(Models CMDN and SMDN).
Screen Label
A 12 character message which appears on the LSS4 message screen as
shown below:
SCREEN LABEL M000
Screen Label and # unacknowledged messages
