EDWARDS SYSTEMS TECHNOLOGY CMDN Installation Operation & Maintenance page 35

WED FEB 6, 1994 11:16:35
Network
Project Description:
Number of Displays: 1
Geographic Category: USA
S Select a display to edit (between 1 and Number of Displays)
D Select Number of Displays
G Select Geographic Category
V Show Version
INSTRUCTIONS
Press any highlighted letter to alter the corresponding item.
Press TAB to move to the next screen and enter data to the
Selected Display shown above.
Press ESC to exit this program.
FCC/DCPU Project Menu
Parameter
Project Name (Filename)
Project Description
Number of Displays
Geographic Category
CMDN Manual
firealarmresources.com
Current time and date information is displayed above the network
status window. The Network Status Window shows the current settings
of the network parameters. To move the cursor to a network parameter,
type the letter highlighted in that parameter name.
PARAMETER ENTRY for ENTIRE PROJECT
Project Name:
PC Communications Port: 1
Type: FCC Class B
The Menu Window lists the network commands available from the
"Parameter Entry for Entire Project" screen. The Instruction Window
provides brief, context sensitive instructions for each operation.
There are up to 11 network parameters on the "Parameter Entry for
Entire Project" screen which must be filled out, depending on the type
of network operation being configured. Only the parameters
appropriate to the system being configured appear on the display.
Move the cursor to the desired parameter window by pressing the key
matching the bold letter in the parameter title.
For example, to move the cursor to the "Geographic Category"
window, press G. A full list of keyboard commands appears in the
Keyboard Command section.
Enter the required annunciator network information for the parameters
listed below. Detailed parameter specifications may be found in the
Parameter Descriptions and Specifications section. The program
automatically enters the default for each parameter. No additional entry
is required if a default parameter is satisfactory.
Annunciator Network Parameters
FCC/DCPU
Class A
Y
Y
Y*
Y
Remote Alpha-Numeric Display
Select Display: 1
Fault Action: 8999
Network Comm Class: B
Network Baud Rate: 9600
X XFER data from this display
A Select Fault Action
P Select PC Communications Port
C Select Network Comm Class
B Select Network Baud Rate
The data here will be saved.
FCC/DCPU IRC-3 (FCC/PCPU)
Class B (Class A or B)
Y Y
Y Y
Y* N
Y Y
Xfer:1
27
