1.4" (3.6 cm)
SYSTEM ANNUNCIATOR
NORMAL
ALARM
SUPERVISORY
TROUBLE
RESET
ALARM
SILENCE
TROUBLE
SILENCE
DRILL/
ALL CALL
[CMDN-008.CDR]
SMDN-C and SAN-4 Enclosure Installation
CMDN Manual
firealarmresources.com
TOP VIEW
11.25" (28.6 cm)
KNOCKOUT FOR 3/4"
CONDUIT (TOP & BOTTOM)
16.25" (41.3 cm)
FRONT VIEW
BACK
NEXT/ACK
DISABLE
ENABLE
E DW ARDS SYS TE MS TE CHNOLO G Y
16" (40.6 cm)
COVER
SIDE VIEW
2.5" (6.4 cm)
13
