Normal LED Steady
Alarm LED Steady
Trouble LED Steady
Supervisory LED Steady
8
Sample IRC-3/FCC Alarm Message:
JAN 23 01:12:56 M123
FIRE ALARM LLPPZZ
Custom Label entered
thru the IBM compatible PC
= Date, time, # of unacknowledged messages (123)
= Alarm type and alarm zone address
= Custom message on two lines (20 x 2)
Sample messages are shown below for annunciators connected to
LSS4 fire alarm panels:
No Messages Pending:
SCREEN LABEL M000
= Screen label and # unacknowledged messages (LSS4 only)
Sample Alarm Message:
SCREEN LABEL M023
FIRE ALARM 000052
Custom Label entered
thru the IBM PC
= Screen Label and # unacknowledged messages
= Alarm Type and Alarm zone address
= Custom message on two lines

LED Operation

LED Indicators
Canada
Steady
Flashing until acknowledged
Flashing until acknowledged
Flashing until acknowledged
firealarmresources.com
Europe
Steady
Steady
Steady
Steady
CMDN Manual
