EDWARDS SYSTEMS TECHNOLOGY CMDN Installation Operation & Maintenance page 37

WED FEB 6, 1994 11:16:35
Current Project File:
Project Name:
Annunciation Type(s): Alarm + Supervisory + Trouble Routing: All Messages
Active When Enabled:
Active When Disabled:
L Enter Location
A Select Annunciation Type(s)
E Select Active When Keyswitch Enabled
D Select Active when Keyswitch Disabled
N Set to No Switch Panel
INSTRUCTIONS
Press letters R, A, C, L, E, D, or B to alter the corresponding item.
Press letters N, T, or H to execute the action stated.
Press TAB to move to the next screen and enter or edit messages.
The Selections shown Above will be saved.
Press ESC to return to prior menu-Selections shown will be saved.
FCC Selected Display Menu
CMDN Manual
firealarmresources.com
PARAMETER ENTRY for SELECTED DISPLAY
Location:
Routing: All Messages
C Select FCC Text
Verify that the address of the first display to be configured appears in
the Base Address window for IRC-3 operations or the Selected Display
window for FCC operation. If not, return to the previous screen by
pressing ESC, then moving the cursor to the Base Address or Selected
Display window by pressing S and use the Up or Down arrow keys
until the desired address appears in the window. When the desired
address appears in the "Base Address" or "Selected Display" Window
press TAB to save the network configuration and return to the
"Parameter Entry for Selected Display" screen.
All information displayed on this screen applies to the CMDN/
Note:
SMDN whose address is displayed in the Base Address or
Selected Display window.
The Parameter Entry for Selected Display screen is the first of two
screens used to configure each CMDN/SMDN (phase 2), and enter its
messages (phase 3).
Enter the required annunciator information for the parameters listed
below. Detailed parameter specifications may be found in the
Parameter Descriptions and Specifications section.
Location
Annunciation Type (FCC only)
Active when Key switch Enabled
Active when Key switch Disabled
No Switch Panel
Printer (Not available on first and last address display panels
on FCC)
Communications Baud Rate (when local printer attached)
Routing (FCC only)
FCC Text (FCC Only)
The data for multiple IRC-3 mode annunciators may be saved
Note:
under the same filename, as long as each annunciator has a different
network address.
Remote Alpha-Numeric Display Network
Select Display: 1
(Comm - No Printer Available)
Baud Rate: 9600
FCC Text: OFF
P Select Printer
B Select Comm Baud Rate
R Select Routing of Mess
T Transmit to Display
H Print Hard Copy (or File)
FCC
29
