FCC Message Entry/Edit Screen
CMDN Manual
firealarmresources.com
MESSAGE ENTRY/EDITING for SELECTED DISPLAY
Project Name:
Location:
_____________
Zone: [_____________]
Configuring the Balance of Annunciators on an FCC Network
When the first annunciator (address 01) has been completely
configured, return to the opening screen and increment the Selected
Display parameter to the next annunciator address and repeat
programming Phase 2 for the next annunciator. When all annunciators
have been configured, proceed to the Downloading to the
CMDN/SMDN section for instructions on downloading.
The DCPU port should be configured in the DCPU Database as a
Note:
"Display" port using the FCC Compiler program.

LSS4 Configuration

Phase 1 - Parameter Entry for Entire Project
The "Parameter Entry for Entire Project" screen is divided into three
sections: the Status Window (top), the Menu Window (middle), and the
Instructions Window (bottom), as shown in the LSS4 menu below.
Current time and date information is displayed above the status
window. The Status Window shows the current settings of the
annunciator parameters.
Remote Alpha-Numeric Display Network
Selected Display:
Printer:
Baud Rate:
Routing:
Current Msg:
Total Msgs:
_____________
[_____________]
FCC
