Alto Lamp Table
Assembly lnstructions - Please keep for future reference
414/3475
hygena
Dimensions
Width - 46cm
Depth - 38cm
Height -70cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
Issue 1-20-05-15
Advertisement
Related Manuals for hygena Alto 414/3475
Summary of Contents for hygena Alto 414/3475
- Page 1 Alto Lamp Table Assembly lnstructions - Please keep for future reference 414/3475 hygena Dimensions Width - 46cm Depth - 38cm Height -70cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800...
- Page 2 Safety and Care Advice Assemble the item as close Check you have all the We do not components and tools listed on to its final position (in the same recommend the pages 2 and 3. room) as possible. use of power Remove all fittings from the drill/drivers for Assemble on a soft level...
-
Page 3: Components - Parts
Components - Parts lf you have damaged or missing components. call the Customer Helpline: 0345 6400 800 underside inside Top panel Side panel (right) (46x38x1.5cm) (37x37x1.5cm) inside underside Base panel Side panel (left) (46x38x1.5cm) (37x37x1.5cm) Drawer back panel x 2 Back panel Leg x 4 (37.9x14x1.2cm) -
Page 4: Tools Required
Components - Fittings 0345 6400 800 Wooden dowel x 8 (6X30mm) Small locking nut x 8 Metal dowel x 16 Large locking nut x 8 Screw x 16 (3x12mm) Drawer runner x 2sets (L300mm) Screw x 20 (3x12mm) Wood screw x 8 (4x30mm) Metal bracket x 4 Screw x 12 (2.2x10mm) Tools required... - Page 5 Assembly Instructions Preparing panels Place top panel , base panel , and drawer fronts flat onto the floor with the fixing holes facing up. Screw metal dowels into each panel as shown. Screw metal dowels as far as shown. Do not overtighten. Assembling side panels cut out edges at back Insert wood dowels...
- Page 6 Assembly Instructions Assembling top panel Insert wood dowels into the top edges of side panels With help, carefully locate top panel into position as shown. Note: Ensure the cut out edge on the top panel correctly located at the back. Insert large locking nuts into side panels Turn locking nuts clockwise...
- Page 7 Assembly Instructions Assembling back panel With help, carefully turn the unit onto it’s front. Place back panel into the recess around the back of the unit. Secure using screws Note: Ensure the unit is straight and square before securing back panel Base Preparing base Secure metal brackets...
- Page 8 Assembly Instructions Attaching legs Screw legs onto metal bracket until they are secure. Do not overtighten. Assembling drawers a: Locate drawer side panels onto drawer front panel Note: Ensure all grooves are correctly located at the bottom. Insert small locking nuts into drawer side panels .
- Page 9 Assembly Instructions Locating drawers With help, turn the whole unit upright. Carefully slide drawers into position as shown. If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Home Retail Group. 489-499 Avebury Boulevard. Saxon Gate West. Central Milton Keynes. MK9 2NW...
