2.7 Wiring Architecture

RS422/RS485 Wiring Architecture
RS232 Wiring
RS232 (RTS/CTS) Wiring
RS232 (RTS/CTS, DTR/DSR) Wiring
RS485 Wiring
RS422 Wiring
When you finish the steps mentioned above and the LED indicators are as shown in above diagram, the converter is
installed correctly. You can use the Setup Tool "EXBrowser.exe" to setup the IP Address.
To proceed the advanced parameter setup, please use a web browser (IE or Netscape) to continue the detailed settings.
Page 10
LAN Cable
HUB
LAN Cable
HUB
LAN Cable
HUB
LAN Cable
HUB
LAN Cable
HUB
EX9132C-2 • Manual Version 1.1 • 21.09.2015
EX9132C-2-MTCP
EX9132C-2-MTCP Serial Device
_____________
TX
_____________
TS
_____________
GND
EX9132C-2-MTCP Serial Device
_____________
TX
_____________
RX
_____________
GND
_____________
CTS
_____________
RTS
EX9132C-2-MTCP Serial Device
_____________
TX
_____________
RX
_____________
GND
_____________
CTS
_____________
RTS
_____________
DSR
_____________
DTR
EX9132C-2-MTCP Serial Device
_____________
D+
_____________
D-
EX9132C-2-MTCP Serial Device
_____________
T+
_____________
T-
_____________
R+
_____________
R-
Manual
RX
TX
GNC
RS
TX
GND
RTS
CTS
RX
TX
GND
RTS
CTS
DTR
DSR
D+
D-
R+
R-
T+
T-
