  • Page 1 12 HP Model# 01925 INVERTER...

  • Page 2: Table Of Contents

    NOTE: This manual is written for the USA market with values with both Standard and Meter values. Other languages are available, such a Spanish and French as per UL60335-2-40. The unit contains R-410A which is a fluorinated refrigerant. Installation must comply with current laws whether local, state or national. The unit may be used by children over 8 years of age and by persons with reduced physical, s ensory or mental capacities, or without the required experience or knowledge, provided they are supervised and have been instructed in the safe use of the unit and understand the hazards involved.
  • Page 3 3 - USE ............................27 3.1 - WarninGS ...........................27 3.2 - Description of the warning panel ....................27 3.3 - Control Panel notifiCationS ....................28 3.4 - USe of tHe remote Control ....................29 3.4.1- insertion of batteries ........................30 3.4.2- replacement of batteries ......................30 3.4.3 - location of the remote controller ....................30 3.5 - DeSCriPtion of remote Control ..................31...

  • Page 4: Warnings

    0 - WARNINGS 0.1 - GENERAL INFORMATION This document is confidential pursuant to the law and may not be reproduced or transferred to third parties without the explicit authorization of the manufacturer. the appliance may undergo updates and therefore have details different from those represented or explained in this manual. 0.2 - SYMBOLS t he pictograms in the next chapter provide the necessary information for correct, safe use of the machine in a rapid, unmistakable way.

  • Page 5: General Warnings

    1. This document is restricted in use to the terms of the law and may not be copied or transferred to third parties without the express authorization of the manufacturer, OLIMPIA SPLENDID. Our units are subject to change and some parts may appear different from the ones shown here, without this affecting the text of the manual in any way.
  • Page 6 16. In the event of operating anomalies (e.g. strange noise, bad odour, smoke, abnormal temperature rise, electric dispersions, etc.) disconnect the electric power supply immediately then contact an Olimpia Splendid USA Service Center or a licensed contractor in you area.
  • Page 7 27. When used in the same space as a fossil fuel appliance you must ensure adequate ventilation. 28. The unit must only be used for comfort cooling applications and is not to be used for other purposed. 29. Do not release R-410A into the atmosphere and follow all applicable codes and standards, both local and national Please refer to Picture #1 on the following page to identify the items listed here: A.

  • Page 8: Descriptive Illustrations

    INVERTER ISTRUZIONI PER USO E MANUTENZIONE 2.4" (61 mm) 3.2" (81 mm) 2.4" (61 mm)
  • Page 10 ø.3" (8 mm) 12" (300...
  • Page 11 8" (203mm) Note: The 8" (203 mm) diameter hole is prefered to achieve the best operating efficiency. Both intake and exhaust holes must be the same size. 6.5" (162 mm) 5.1" (130mm)
  • Page 12 1/4" (6 mm)
  • Page 16 26' (8m) 3.2" (80mm)
  • Page 17 min. 5qts (4.8L)

  • Page 18: Description Of The Unit

    1 - DESCRIPTION OF THE UNIT 1.1 - LIST OF THE COMPONENTS SUPPLIED The parts listed below and shown in figure 1 are included in the supply, the other particulars necessary for installation must be purchased. F. Internal flanges (x 2) A. MAESTRO PRO G. Sheet for wall pipes (x 2) B. remote control H. Kit of screws and anchor bolts B1. Battery for remote control quantity 2 - aaa t ype x 1.5V L.

  • Page 19: Storage

    1.2 - STORAGE Store the cartons in an area protected from outdoor conditions and raised off the floor by a pallet. DO NOT TURN THE PACKAGING UPSIDE DOWN NOR PLACE IT HORIZONTALLY. 1.3 - RECEIPT AND UNPACKING The units are delivered complete and intact. However please follow the warnings below: a.

  • Page 20: Installation

    Failure to follow the instructions may cause the unit to fail. Doing so voids the unit warranty and relieves Olimpia Splendid and any of its agents or distributors from liability for possible damages caused to people, animals or the space.

  • Page 21: Unit Assembly

    The unit must be installed on an outside wall! After determining the best place for installation as described above, check for the absence of other structures or systems (beams, piers, pipes, wires, etc.) at the points where the holes are to be drilled, which would prevent drilling the holes required to install the unit.

  • Page 22: Preparing The Condensate Discharge

    Drill the holes for the ductwork tilted slightly down, with the low end to the outside wall, to ensure rainwater that may enter the duct will flow back out. (fig. 5). Most of the removed material is expelled outwards, therefore make sure that it does not hit any person or object when it falls out.

  • Page 23: Assembly Of The Air Ducts And External Grids

    2.4.3 - Assembly of the air ducts and external grids After drilling or cutting the holes, insert the supplied plastic sheet (fig.11, ref.G) into the holes. The sheet (G) was made for 8"(202mm) holes, you will have to cut off 5" (127mm) from the long side of the sheet if using the optional 6.5" (162mm) holes (fig. 11). The sheets should be cut 2"...

  • Page 24: Positioning Of The Device On The Anchor Brackets

    2.4.5 - Positioning of the device on the anchor brackets Using the two previously drilled holes (see fig.6), mount the support brackets (L) to the wall using the supplied wall plugs screws (H) (fig. 24). Check to ensure the support brackets are firmly anchored to the wall. Proceed as follows: Apply adhesive tape (A) to have references to the hooking points of the unit (fig. 25).The tape can be removed once the unit has been hooked to the wall. Raise the unit holding it by the sides of the lower base and hook it to the brackets (fig.26, ref.L).

  • Page 25: Top/Bottom Installation Configuration

    to replace the power cord, proceed as follows: Raise the return grill and remove the two screws (fig.28, ref.3A). b. Extract the right (release using a screwdriver) and left (1a) doors of the front cover, then rotate the flap (1) and remove the three screws (1b) and the two screws (1c) (fig. 29). Remove the front cover (fig.30). d. Unscrew the two screws (X2) to remove the front cover of the switchgear (X1) (fig. 31). Unscrew the two screws (X4) to remove the top cover of the switchgear (X3) (fig. 32). extract the switch towards the exterior of the switchgear (fig. 34-A). g. Unscrew cable clamp (J1) (fig. 33). h. Unscrew the cable's locking screws on the terminal board (J2) (fig. 33) Remove the old cable, then install the new one by reversing the steps shown above.

  • Page 26: Energy Boost/System Enable Contact Input

    2.6 - ENERGY BOOST/SYSTEM ENABLE CONTACT INPUT the input located on the terminal (Y2) of the main board (Y1) can be used to activate the functions ENERGY BOOST or SYSTEM ENABLE of the unit (fig. 46). Configuration and use of the input ENERGY BOOST or SYSTEM ENABLE IS AS FOLLOWS: Power up the unit and make sure it's switched to stand-by mode. b.

  • Page 27: Use

    3 - USE 3.1 - WARNINGS The installation and electrical connections of the unit should be carried out by a service technician qualified as per local, state or national requirements. No structural object (furniture, curtains, plants, leaves, blinds, etc.) should ever obstruct the normal flow of air from either the internal or external gratings.

  • Page 28: Control Panel Notifications

    Keys LED1 LED5 MODE Before performing the following operations, press one of the keys to enable the console. increase in the desired temperature. Maximum value Display settable is 86ºF (30ºC). Decrease in the desired temperature. Minimum value settable in heating mode is 61ºF(16°C). In cooling mode it's 64°F (18°C).

  • Page 29: Use Of The Remote Control

    OPERATING CONDITIONS DISPLAY LED5 LED1 minimum fan speed automatic fan speed timer enabled filter dirty report* energy Boost contact opening (par. PI>0) System enable contact opening (par. PI=0) Keypad locked Top/Bottom wall configuration parameter Ceiling installation floor installation * reset as described in paragraph 3.2 3.4 - USE OF THE REMOTE CONTROL The remote control allows the user to operate the unit in the most efficient way possible.

  • Page 30: 1- Insertion Of Batteries

    3.4.1 - Installing of batteries To insert the batteries correctly (fig.35): a. Remove the battery compartment cover. b. Insert the batteries into the r compartment. Check the polarity of the batteries as indicated on the bottom of the compartment. c. Close the compartment ( fig. 36). 3.4.2 - Replacement of batteries Batteries should be replaced when the display on the remote control does not appear sharp or when the remote control does not change the settings.

  • Page 31: Description Of Remote Control

    3.5 - DESCRIPTION OF REMOTE CONTROL the remote control is the interface between the unit and the customer, so it is very important to learn all its functions, the use of the various controls and the meaning of the symbols marked on it.

  • Page 32: Description Of Unit Functions

    3.6 - DESCRIPTION OF THE UNIT'S FUNCTIONS 3.6.1 - Main switch-on and running management • The unit is equipped with a power switch (10) positioned in the upper right corner under the door (7); the switch (10) must be positioned to “I” (fig. 38) in order to work. Place switch in the “I” position to start the unit. • Once these operations have been carried out, the unit may be regulated using the remote control. in order to transmit commands to the indoor unit, point the front of the remote control toward the unit’s control panel.

  • Page 33: Operation In "Fan" Mode Only

    3.6.6 - Operation in “FAN” mode • In this mode the unit does not perform any action with regard to temperature and humidity in the room. • To activate: Press several times key B5 on the remote control until when the automatic FAN symbol D18 (fan + first notch) appears on its display. 3.6.7 - Operation in “Spa” mode (Automatic) • In this mode the unit’s temperature is regulated according to the room’s temperature. The fan speed is also regulated according to the temperature setpoint (except in dehumidification mode). •...

  • Page 34: Silent Key

    3.6.11 - SILENT (Night) key • To activate this mode, first select the desired operational mode and user setpoint. Then press the B3 key on the remote control. The D14 symbol will appear on the display). • The activation of Silent (night) mode results in the following changes: - Gradual increase in the user selected temperature during cooling mode - Gradual decrease in the user selected temperature for heating - Reduction of the sound level...

  • Page 35: Timer Setting

    3.6.14 - Timer setting (PROGR. 1 and PROGR. 2) it is possible to set one or both the timer programs. t o set the unit activation and deactivation times in the two programs, use the remote control and work as follows: Press the B9 key once or serveral times (Set timer) until the 1 symbol (D6) and the ON symbol (D10) appear on the display.

  • Page 36: Managing The Unit If The Remote Control Is Not Available

    3.6.17 - Managing the unit if the remote control is not available In case the remote control lost or malfunctions the unit can be controlled from the keys on the unit itself. 3.7 - RECOMMENDATIONS FOR ENERGY SAVINGS Below find simple recommendations for reducing consumption: • Always and constantly keep the filters clean (see maintenance and cleaning chapter). •...

  • Page 37: Maintenance

    4.2 - MAINTENANCE if the unit will be unused for an extended period it is recommended that you unplug or de-energize the unit and remove the batteries from the remote control 4.2.1 - Routine maintenance The unit requires periodic maintenance to ensure peak performance while using the lowest energy possible.

  • Page 38: Diagnosis, Alarms And Inconveniences

    4.3 - DIAGNOSTICS and ALARMS 4.3.1 - Diagnosing Alarms it is important for the user to distinguish between functional problems and problems with unit performance when compared to normal operation. The most common problems may easily be resolved by the user. (See paragraph: a nomalies and solutions).

  • Page 39: Anomalies And Remedies

    4.3.4 - Anomalies and remedies Malfunctioning Cause What must be done? The unit will not start. Current failure Wait for the current to be restored. the unit is disconnected from the Check that the plug is inserted in the current. wall socket.

  • Page 40: Technical Data

    5 - TECHNICAL DATA Design Specifications and Capacities* Maestro Pro 12 HP 01925 Model Number AC Volts/Phase/Hertz 115-1-60 Voltage (min 109, max 127) BTUh/Kw 8,150/2.4 Rated Capacity for both Cooling & Heating (1) BTUh/Kw 11,600/3.4 Maximum Capacity for both Cooling and Heating (2) Watts Rated Power Consumption - Cooling Mode Watts...

  • Page 41: Warranty

    LIMITED WARRANTY USA & CANADA Thank you for purchasing this Olimpia Splendid USA unit. This unit is covered by a limited 7 year compressor, a 2 year parts warranty and a 1 year limited unit replacement should the compressor fail within the first 12 months from date of startup.

  • Page 42: Startup And Troubleshooting Data Sheet

    Startup and Troubleshooting Data Sheet Model #____________________ Serial #__________________________ Unit Owner_____________________ Phone #_____________________ Start Up Date________ Owner Address 1___________________________________Address 2_______________________ City or Province____________________________________ State______ Zip Code____________ Installing Contractor_________________________________________ Phone # _______________ Technician Name___________________________________________ Phone # _______________  Prior to Install verify model number to insure proper unit selection ...
