  • Page 1 INVERTER INSTRUCTION FOR USE AND MAINTENANCE...
  • Page 2 1. The appliance contains R-410A gas. R-410A is a fluorinated greenhouse gas. 2. Comply with current laws. 3. Take care as R-410A refrigerant is odourless. 4. The appliance may be used by children over 8 years of age and by persons with reduced physical, sensory or mental capacities, or without the required experience or knowledge, provided they are supervised or have been instructed in the safe use of the appliance and understand the hazards involved. 5. Children must not play with the equipment. 6. Children must not be allowed to clean the appliance or perform user maintenance without proper supervision. 7. If the power cable is damaged, it must be replaced by the manufacturer or by its technical support service or by similarly qualified personnel, to prevent any risk to the user. 8. Installation, initial start-up and subsequent maintenance, with the exception of the ambient air filter cleaning and washing, must be carried out solely by authorized and qualified personnel. 9. To prevent any risk of electric shocks, it is mandatory to disconnect the plug from the power socket and/or to switch off the main switch before performing any electrical connection and any maintenance operation on the appliances. 10. During installation, respect the references to the minimum spaces indicated in figure 2. 1. L’appareil contient du gaz R-410A. L’R-410A est un gaz à effet de serre fluoré. 2. Respecter les lois en vigueur. 3. Attention : le réfrigérant R-410A est inodore 4. L’appareil peut être utilisé par des enfants d’au moins 8 ans et par des personnes ayant des capacités physiques, sensorielles ou mentales réduites, ou dépourvues de l’expérience ou des connaissances nécessaires, à condition que ce soit sous surveillance ou qu’elles aient reçu des instructions relatives à l’utilisation sûre de l’appareil et à la compréhension des dangers qui y ont liés. 5. Les enfants ne doivent pas jouer avec l’appareil.
  • Page 3 1. El aparato contiene gas R-410A. R-410A es un gas de efecto invernadero fluorado. 2. Respete las leyes vigentes. 3. Atención: se recuerda que el refrigerante R-410A es inodoro 4. El aparato puede ser utilizado por niños mayores de 8 años y por personas con capacidades físicas, sensoriales o mentales reducidas, o carentes de la experiencia y conocimiento necesarios, siempre que lo hagan bajo vigilancia o después de haber recibido instrucciones sobre el uso seguro del aparato y sobre los peligros inherentes al mismo. 5. Los niños no deben jugar con el aparato. 6. Las operaciones de limpieza y mantenimiento a cargo del usuario no deben ser realizadas por niños sin vigilancia. 7. En caso de deterioro del cable de alimentación, debe ser sustituido por el fabricante, por el servicio de asistencia técnica o por una persona con cualificación similar, para prevenir cualquier riesgo. 8. La instalación, la primera puesta en marcha y las posteriores operaciones de mantenimiento, excepto la limpieza o el lavado del filtro de aire ambiente, deben ser realizadas exclusivamente por personal autorizado y cualificado. 9. Para prevenir cualquier riesgo de electrocución, es imprescindible desconectar el enchufe de la toma de corriente y/o apagar el interruptor general antes de efectuar conexiones eléctricas y cada operación de mantenimiento en los aparatos. 10. Durante la instalación, respete las referencias a los espacios mínimos indicados en la figura 2.
  • Page 4 INSTRUCTION FOR USE AND MAINTENANCE MODE D’EMPLOI ET D’ENTRETIEN INSTRUCCIONES PARA EL USO Y EL MANTENIMIENTO min 60 2,4” 3,2” min 60 2,4” 4”...
  • Page 6 ø8mm 0,3” 11,8”...
  • Page 7 ø202 8” ø162 6,4” 5,1”...
  • Page 8 ø 6 mm 0,24”...
  • Page 12 315” min. 80 3,2”...
  • Page 13 min. 5 L 1,3 gal...

  • Page 15: Table Of Contents

    3.6.1 - main switch-on and running management ..................23 3.6.2 - eCo key ............................23 3.6.3 - turning the unit on/off .......................23 3.6.4 - operation in “Cooling” mode only....................23 3.6.5 - Operation in “Dehumidification” mode only ...................23 3.6.6 - operation in “Ventilation” mode only .....................24 EN - 1 MAESTRO PRO INVERTER...
  • Page 16 3.6.7 - operation in “Spa” mode only (automatic) ..................24 3.6.8 - Operation in “Heating” mode only (only models fitted with heating pump) ........24 3.6.9 - Checking airflow direction ......................25 3.6.10 - Checking fan speed ........................25 3.6.11 - Silent key ..........................25 3.6.12 - timer setting ..........................25 3.6.13 - timer and clock setting .......................26 3.6.14 - timer setting ..........................26 3.6.15 - timer activation and deactivation ....................27 3.6.16 - reset of all the remote control functions ..................27 3.6.17 - managing the unit if the remote control is not available ..............27...

  • Page 17: Warnings

    - danger of injury to the operators - loss of the warranty - refusal of liability by the manufacturer. Raised hand refers to actions that absolutely must not be performed. EN - 3 MAESTRO PRO INVERTER...
  • Page 18 DANGER OF HIGH VOLTAGE Signals to the personnel that the operation described could cause electrocution if not performed according to the safety rules. GENERIC DANGER it informs the personnel concerned that if the operation is not carried out in compliance with the safety regulations, it presents the risk of suffering physical damage.

  • Page 19: General Warnings

    1. This document is restricted in use to the terms of the law and may not be copied or transferred to third parties without the express authorization of the manufacturer, OLIMPIA SPLENDID. Our machines are subject to change and some parts may appear different from the ones shown here, without this affecting the text of the manual in any way.
  • Page 20 12. In case of replacement of parts, use only original OLIMPIA SPLENDID parts. 13. IMPORTANT! In order to prevent any risk of electrical shocks, it is essential to disconnect the plug from the power socket and/or to switch off the main switch (“OFF”)
  • Page 21 This must attest skill in safely handling refrigerants in compliance with assessment specification acknowledged by sector associations. 34. Do not emit R-410A gas into the atmosphere; R-410A is a fluorinated greenhouse gas with a Global Warming Potential (GWP) = 2088. EN - 7 MAESTRO PRO INVERTER...

  • Page 22: Notes Regarding Fluorinated Gases

    (on demand) for the sole purpose of obtaining a comfortable temperature in the room. • An improper use of the devices (external and internal) with possible damages caused to people, things or animals relieves OLIMPIA SPLENDID from any liability. 0.6 - HAzARDOUS zONES • The climate controllers must not be installed in environments with the presence of inflammable gases, explosive gases, in very humid environments (laundries, greenhouses, etc.), or in places with other machines that generate a strong...

  • Page 23: Description Of The Appliance

    Before beginning to assemble the unit, make sure all the parts are within easy reach. The parts listed below and shown in figure 1 are included in the supply, the other particulars necessary for installation must be purchased. A. appliance maeStro Pro F. Internal flanges (x 2) B. remote control G. Sheet for wall pipes (x 2) B1.

  • Page 24: Appliance Components Description

    A failure to implement the indicated standards, which may cause a malfunction of the appliances, relieves OLIMPIA SPLENDID from any form of warranty and from any liability for possible damages caused to people, animals or things. The electrical system must be compliant with legal standards, must respect the data in the technical data sheet and be must be equipped with an efficient ground system.

  • Page 25: Size And Specifications Of The Room In Which To Install The Air Conditioner

    Check again to make sure there are no obstacles to air circulation through the holes to be drilled due to plants and their leaves, slats or panelling, blinds, grat- ings or grids too dense, etc.). EN - 11 MAESTRO PRO INVERTER...

  • Page 26: Unit Assembly

    2.4 - UNIT ASSEMBLY The maximum allowed length of the pipes is 1 m (39”), the pipes must be internally smooth, with a diameter equal to 202 mm (8”) or 162 mm (6,4”) and bends cannot be performed. It is necessary to use the grilles provided, or grilles which keep the same features. 2.4.1 - Drilling the wall Install the unit by drilling two holes,diameter of either 162 mm (6,4”) or 202 mm (8”), in the wall as indicated in the drilling template.

  • Page 27: Preparing The Condensate Discharge

    In the event of prolonged operation during the winter with temperatures below 41°F, install the optional basin heater kit. EN - 13 MAESTRO PRO INVERTER...

  • Page 28: Assembly Of The Air Ducts And External Grids

    2.4.3 - Assembly of the air ducts and external grids • After drilling the holes (with the core drill), insert the plastic sheet (G) supplied with the air conditioner (fig. 11) inside them. Since the sheet (G) was made for 202 mm (8”) holes, you will have to cut off 130 mm (5,1”) from the long side of the sheet for the 162 mm (6,4”) holes (fig. 11). The sheets must be 65 mm (2,5”) shorter than the length of the wall. • Roll the sheet (G) and insert it into the hole, paying attention to the splicing line, which must always face upwards. (fig.12). Use an ordinary cutter for the foregoing operation (fig. 12). To position the external grids, proceed as follows: a. Apply the seal (F) to the wall flange (D), ensuring it lines up with the outer edge of the flange as indicated in the figure 13.

  • Page 29: Electric Hook-Up

    It is, however, necessary to check that the electrical power supply is equipped with efficient earthing and with adequate protections against overloading and/ or short circuits (a type 15 AT delayed fuse or other devices with equivalent functions are recommended). Use a single outlet circuit only. EN - 15 MAESTRO PRO INVERTER...

  • Page 30: Top/Bottom Installation Configuration

    • This operation must be performed only by the installer or any similarly qual- ified personnel and in compliance to the current national regulations. • To prevent the risk of an electric shock it is mandatory to switch off the main switch before performing the electrical connections or any maintenance op- eration to the appliances.

  • Page 31: Energy Boost/System Enable Contact Input

    Unscrew the two fixing screws (X2) to remove the front cover of the switchgear (X1) (fig. 31). e. Remove the supplied jumper (Y3) from the screw terminal (Y2) (fig. 47). Close the switchgear. g. reassemble the front cover of the machine. the input must be piloted by a potential-free dry contact. Do not use a cable longer than 10 meters. EN - 17 MAESTRO PRO INVERTER...

  • Page 32: Use

    3 - USE 3.1 - WARNINGS The installation and electrical connection of the air conditioner should be carried out by specialized personnel who possess the requisites set forth by law. The installation instructions are contained in the appropriate paragraph of this manual. No structural object (furniture, curtains, plants, leaves, blinds, etc.) should ever obstruct the normal flow of air from either the internal or external gratings.

  • Page 33: Control Panel Notifications

    Buzzer 3.3 - CONTROL PANEL NOTIFICATIONS The console includes the notifications listed below. OPERATING CONDITIONS DISPLAY LED5 LED1 Stand-by Cooling mode 18÷30°C/64÷86f BlUe Heating mode 16÷30°C/61÷86f Dehumidification mode BlUe Ventilation mode automatic mode maximum ventilation speed medium ventilation speed >>> EN - 19 MAESTRO PRO INVERTER...

  • Page 34: Use Of The Remote Control

    OPERATING CONDITIONS DISPLAY LED5 LED1 minimum ventilation speed automatic ventilation speed timer enabled filter dirty report* energy Boost contact opening (par. PI>0) System enable contact opening (par. PI=0) Keypad locked Top/Bottom wall configuration parameter Ceiling installation floor installation * reset as described in paragraph 3.2 3.4 - USE OF THE REMOTE CONTROL the remote control supplied with the air-conditioner is the instrument that enables you to use the appliance in the most...

  • Page 35: Insertion Of Batteries

    • Keep the remote control in a position from which the signal can reach the appliance receiver (maximum distance is about 8 meters - with charged batteries) (fig. 37). the presence of obstacles (furniture, curtains, walls, etc.) between the remote control and the appliance reduces the remote control range. EN - 21 MAESTRO PRO INVERTER...

  • Page 36: Description Of Remote Control

    3.5 - DESCRIPTION OF REMOTE CONTROL the remote control is the interface between the air-conditioner and the customer, so it is very important to learn all its functions, the use of the various controls and the meaning of the symbols marked on it.

  • Page 37: Description Of The Air Conditioner Functions

    3.6.5 - Operation in “Dehumidification” mode only • When used in this mode, the air conditioner eliminates the humidity in the room. this function can be extremely useful between seasons, particularly on rainy days when the temperature is not uncomfortable but the excess humidity feels unpleasant. • In this mode, both room temperature and fan speed settings are ignored, which correspond to minimum. EN - 23 MAESTRO PRO INVERTER...

  • Page 38: Operation In "Ventilation" Mode Only

    • Any fan temperature and speed indication then disappears from the display (LED6) of the control panel (fig.C). • To activate this mode, press several times key B5 on the remote control until when symbol D3 and the automatic ventilation symbol D18 (fan + first notch) appear on its display. • In this operating mode it is normal for the air conditioner to function intermittently. 3.6.6 - Operation in “Ventilation” mode only • When used in this mode the air conditioner does not perform any action with regard to temperature and air humidity in the room. • To activate this mode, press several times key B5 on the remote control until when the automatic venti- lation symbol D18 (fan + first notch) appears on its display.

  • Page 39: Checking Airflow Direction

    3.6.12 - Timer setting • The appliance logic allows the User to make use of two different timer programs (see paragraph 3.6.14), thanks to which the appliance can be deactivated and activated (or vice versa) whenever desired (for example, it can be activated shortly before returning home so as to find an already pleasant temperature in the room). • Firstly, if it is desired to make use of these functions, set the correct time (see paragraph 3.6.13) and then set the timer as you prefer. EN - 25 MAESTRO PRO INVERTER...

  • Page 40: Timer And Clock Setting

    3.6.13 - Timer and clock setting to set time, work with the remote control as follows: Press key B9 (Set timer) until when the hour indication h (D11) appears on the display b. Set the hour with keys B6 (+) and B7 (-) . Press the key B9 until when the minutes indication m (D11) appears on the display.

  • Page 41: Timer Activation And Deactivation

    (or the upstream master isolating switch is positioned at “0” OFF). Do not touch the metal parts of the unit when removing the air filters. They are very sharp. Cuts or injury risk. EN - 27 MAESTRO PRO INVERTER...

  • Page 42: Cleaning

    4.1 - CLEANING 4.1.1 - Appliance and remote control cleaning Use a dry cloth to clean the appliance and the remote control (fig. 44). it is possible to use a cloth moistened with cold water to clean the appliance if it is very dirty. Suck between the air inlet and outlet grilles (fig. 44). Do not use a chemically treated or antistatic cloth to clean the appliance. Do not use gasoline, solvent, polish or similar solvents.

  • Page 43: Condensation Water Drainage In Case Of Emergency

    For all the other reports (see paragraph: 4.3.3 - Console alarms), it is necessary to always contact the technical assistance service” Any attempt to repair the appliance by unauthorised personnel will immediately invalidate any form of guarantee. EN - 29 MAESTRO PRO INVERTER...

  • Page 44: Functional Aspects Not To Be Mistaken For Anomalies

    4.3.2 - Functional aspects not to be mistaken for anomalies the following events may occur during normal operation: The compressor does not start up again immediately after a stop (it takes about three minutes to start again). in the operating logic of the appliance a delay between a compressor stop and its successive restart has been included, so that the compressor itself is protected against activations that are too frequent.

  • Page 45: Anomalies And Remedies

    Disable the keypad lock from the report console keys don’t work. report console. if the problem has not been solved, please contact the nearest technical assistance service. Please give detailed information about the malfunction and on the equipment version. EN - 31 MAESTRO PRO INVERTER...

  • Page 46: Technical Data

    5 - TECHNICAL DATA For the technical data listed below, consult the characteristic data plate affixed to the product. • Power supply voltage • maximum power absorbed • maximum current absorbed • Cooling capacity • refrigerant gas • Protection rating of the casings •...
