- Page 1 User Manual PPC-IPS-100/150 Intelligent Power System for PCs...
- Page 2 The documentation and the software included with this product are copyrighted 2024 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
- Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Contact your local supplier for ordering information.
- Page 4 환경에서 사용하는 경우 전파간섭의 우려가 있습니다. The power outlet socket should have a ground connection. DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. PPC-IPS-100/150 User Manual...
- Page 5 (將電池投入火中 或熱烤箱中，或將其機械破碎或切割，可能導致爆炸) Leaving the battery in environments with extremely high temperatures can cause an explosion or leakage of flammable liquid or gas. (將電池放置在極端高 溫的環境中，可能導致爆炸或易燃液體或氣體洩漏) PPC-IPS-100/150 User Manual...
- Page 6 PPC-IPS-100/150 User Manual...
-
Page 7: Table Of Contents
Operating Temperature for the Battery Pack ......19 UI Introduction - Advanced..............20 4.2.1 Time to Shutdown after Power Outage........20 4.2.2 Maximum Time to Shutdown after Power Outage ...... 20 4.2.3 Time to Turn Off IPS after a Shutdown Command ..... 20 PPC-IPS-100/150 User Manual... - Page 8 PPC-IPS-100/150 User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information Introduction Specifications Dimensions... -
Page 10: Introduction
Note***: If the battery is not used for an extended period, ensure it has a certain amount of charge before storage. Store the battery in a cool, dry place. Charge the battery once every six months to prevent deep discharge during prolonged storage. PPC-IPS-100/150 User Manual... -
Page 11: Dimensions
Place the bat- tery pack in a well-ventilated area and promptly contact us. Dimensions Figure 1.1 PPC-IPS with Baseboard The VESA mount should be affixed using M4 screws at a maximum depth of 8 mm / 0.31 in. PPC-IPS-100/150 User Manual... - Page 12 Figure 1.2 Installation via DIN-Rail Mount 66.00 9.00 35.00 Figure 1.3 DIN-Rail Bracket Dimensions PPC-IPS-100/150 User Manual...
-
Page 13: Chapter 2 Installation Instructions
Chapter Installation Instructions... -
Page 14: Introduction
This helps to delay system shutdowns, allowing work to be finished and reduc- ing data losses. Once the shutdown delay interval has expired, the module sends a shutdown order to the PC. Auto shut down through RS-232 by Software Utility PPC-IPS-100/150 User Manual... -
Page 15: Auto-Shutdown Modes
*In max. power mode, the PPC-IPS module optimizes power consumption to support a maxi- mum length of time based on the remaining battery capacity. RS-232 Mode Connect the PPC-IPS module to the PC using the PPC-IPS control cable. PPC-IPS-100/150 User Manual... -
Page 16: System I/O
When placed upright, the PPC-IPS module will appear as shown in Figure 2.3. B: Status F: Ground E:DC IN D:DC OUT C:RS-232 (for indicators connecting a PC) A: system reset B: Status F: Ground E:DC IN D:DC OUT C:RS-232 (for indicators connecting a PC) A: system reset PPC-IPS-100/150 User Manual... -
Page 17: Installation Procedures
Installation Procedures 2.4.1 VESA Mount Installation Remove the 4 VESA mount screws from the PPC. Use the 4 screws to attach the PPC-IPS as in the following figure. PPC-IPS-100/150 User Manual... -
Page 18: Din-Rail Installation
Mode A Mode B Figure 2.1 DIN-Rail Mounting Note! DIN-rail screw type: M3 Maximum screw depth: 5 mm/0.19 in After the DIN-rail bracket is secured to the PPC-IPS module, mount the bracket onto the DIN-rail as shown below. PPC-IPS-100/150 User Manual... -
Page 19: Module Installation
Module Installation In the instructions provided below, a VESA mount is used as the demonstration example. PPC-IPS-150 1. DC-IN cable 2. Power out cable 3. COM transmission cable 4. USB control cable (Linking for special application requirements) PPC-IPS-100/150 User Manual... -
Page 20: Replace The Ips Battery
3. COM transmission cable 4. USB control cable (Linking for special application requirements) 2.4.4 Replace the IPS Battery Remove the affixing screws on the top cover of the PPC-IPS module (circled in red below). Figure 2.3 Top Cover Screw Locations PPC-IPS-100/150 User Manual... - Page 21 Push out the battery in the direction of the arrow and replace it with a new one. (Be sure to detach the battery from the battery connect completely before removing the battery) Assemble the battery, battery bracket, and back cover according to the previous steps. PPC-IPS-100/150 User Manual...
- Page 22 PPC-IPS-100/150 User Manual...
-
Page 23: Chapter 3 Ips Settings
Chapter IPS Settings... -
Page 24: I/O Connector Specifications
PPC will shutdown Table 3.2: Control Interface PPC-IPS-150 PLUG-3 PPC-IPS-100 DB9 RS-232_RX RS-232_TX RS-232_RX RS-232_TX PPC-IPS-150 interface: Phoenix connector, 3 pin, 3.5 mm pitch PPC-IPS-100 interface: DB9 Table 3.3: DC Out Name Type Description DC-OUT(+) Output 24V+/-10% provide to PC DC-OUT(-) Output PPC-IPS interface: Phoenix connector, 2pin, 5.00 mm pitch... -
Page 25: Chapter 4 Ppc-Ips Adjustment Tool
Chapter PPC-IPS Adjustment Tool... -
Page 26: Ui Introduction - Basic
Status indicators provide a convenient way to determine the PPC-IPS module status/ activity. Green indicates normal status and Red indicates abnormal status. DC-In: indicates whether the DC power source is active Battery: indicates whether the battery is functioning normally PPC-IPS-100/150 User Manual... -
Page 27: Final Countdown For Shutdown
Operating Temperature for the Battery Pack This option allows you to configure the battery pack temperature. Note! The maximum operating temperature tolerated is 50 °C/122 °F. The operating temperature of battery pack: charge: 0-50 °C no charge: 0-60 °C PPC-IPS-100/150 User Manual... -
Page 28: Ui Introduction - Advanced
This option allows users to configure the time before turning off the PPC-IPS module after a shutdown/hibernate signal is sent to the panel PC to protect the battery life. The time interval can be between 1 and 5 minutes. PPC-IPS-100/150 User Manual... - Page 29 PPC-IPS-100/150 User Manual...
- Page 30 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024...
