- Page 1 User Manual Intelligent Power System (iPS) iPS-M S series Power System...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Technical Support and Assistance Visit the Advantech website at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
- Page 4 Visit the Advantech websites at www.advantech.com or www.advantech.com.tw where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: ...
- Page 5 Liquid has penetrated into the equipment. The equipment has been exposed to moisture. The equipment does not work well, or you cannot get it to work according to the user's manual. The equipment has been dropped and damaged. iPS-M S series User Manual V.A1...
- Page 6 Use a power cord that matches the voltage of the power outlet, which has been approved and complies with the safety standard of your particular country. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 7 Explanation of Graphical Symbols IEC 60878 and ISO 3864-B.3.6 : Warning: dangerous voltage. ISO 7000-0434: Attention, consult ACCOMPANYING DOCUMENTS. ISO 7000-1641: Follow operating instructions or Consult instructions for use. IEC 60417 -5009: SANDY-BY. IEC 60417-5031: Direct current. iPS-M S series User Manual V.A1...
- Page 8 PC is on. Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive elec- tronic components. iPS-M S series User Manual V.A1 viii...
-
Page 9: Table Of Contents
2.4.3 Low Capacity Warning ..............11 Battery Pack Replacement..............12 Chapter Battery Maintenance ......15 Regular Use .................... 16 Storing the Battery .................. 16 Trouble Shooting..................17 Chapter EMC Table ..........19 EMC Table ....................20 iPS-M S series User Manual V.A1... - Page 10 S series User Manual V.A1...
-
Page 11: Chapter 1 General Information
Chapter General Information... -
Page 12: Introduction
Alerts (battery capacity, temperature, warning) Battery Life cycle statistics Report & log file Power Manager AMiS_Link Client Installation Software Server Installation (Optional) Multi-language support, including Chinese Tradi- tional, Chinese Simple, English, German and Dutch iPS-M S series User Manual V.A1... -
Page 13: Remote Control Specifications
54 x 23 x 12 mm (2.1 x 0.9 x 0.4 inch) Physical Characteristics Weight 0.4kg DC-In 12-24Vdc, 8-3A Mode 1: 12Vdc, 6A I/O ports Mode 2: 15Vdc, 5A DC-Out Mode 3: 16Vdc, 5A Mode 4: 19Vdc, 4A iPS-M S series User Manual V.A1... -
Page 14: Dimensions
1.5 Dimensions iPS-M S series User Manual V.A1... -
Page 15: Chapter 2 Getting Started
Chapter Getting Started... -
Page 16: Overview Of Ips-M Power System
Figure 2.1 I/O Ports and AC Connector The front side view, figure 2.2 AC On/Off Switch Figure 2.2 Front and Top View with AC Switch iPS-M S series User Manual V.A1... -
Page 17: Overview Of Ips-M Remote Control
(press and hold for at least 7 seconds) to turn on power. Figure 2.4 Connecting the AC power cord with iPS-M battery Plug AC power cord Turn on switch Figure 2.5 AC power cord connecting and power switch on iPS-M S series User Manual V.A1... - Page 18 Figure 2.6 AC power switch on Connect remote control Figure 2.7 Connecting the remote control Press the power button and hold for 7 seconds to turn on battery power Figure 2.8 Power ON battery iPS-M S series User Manual V.A1...
-
Page 19: Battery Discharging
Then connect the cable to the battery system and equipment. Press power button and hold for 7 seconds to turn off battery power. When power is off, all LED light will go off. Figure 2.9 Battery power off iPS-M S series User Manual V.A1... -
Page 20: Discharging Time Estimation
(PC or Device). For example, assuming power consumption of the loader is 40Wh, discharging time for different capacities of iPS-M batteries is listed following: Model Discharging Time Estimation iPS-M420S 8 ~10 hours (400Wh / 40 Wh) iPS-M210S 4~ 5 hours (200Wh / 40Wh) iPS-M S series User Manual V.A1... -
Page 21: Low Capacity Warning
AC power is plugged in. When battery capacity is 0%, the bat- tery system shuts down automatically. RED LED keeps flashing Warning! When the battery capacity is 0%, you MUST RECHARGE WITHIN 48 HOURS to keep the battery cell alive and extend the battery life. iPS-M S series User Manual V.A1... -
Page 22: Battery Pack Replacement
2.5 Battery Pack Replacement iPS-M power system allows to do battery pack replacement in just 4 easy steps. Turn AC power switch off. Turn off switch Turn off switch Remove top cover screws and top cover. iPS-M S series User Manual V.A1... - Page 23 Remove screws on battery pack holder. Disconnect battery cell cable and system cable to remove old battery cell and replace new one. Reverse above steps to reassemble the battery system. iPS-M S series User Manual V.A1...
- Page 24 S series User Manual V.A1...
-
Page 25: Chapter 3 Battery Maintenance
Chapter Battery Maintenance... -
Page 26: Regular Use
If battery is not to be used or put in idle mode for a long time, recharge to 100% than move to the warehouse. It is also suggested to perform a recharge regu- larly: For 400Wh power system: every 1 year For 200Wh power: every 6 months iPS-M S series User Manual V.A1... -
Page 27: Trouble Shooting
Warning! When battery is going to be stored for a long time, make sure to recharge it to 100% capacity. If stored in a warehouse over 1 year, you need to do regular recharges: Every year for 400Wh power system Every 6 months for 200Wh power system iPS-M S series User Manual V.A1... - Page 28 S series User Manual V.A1...
-
Page 29: Emc Table
Chapter EMC Table... -
Page 30: Emc Table
Power frequency mag- Power frequency netic fields should be at (50/60 Hz) levels characteristic of a magnetic field 3 A/m 3 A/m typical location in a typi- cal commercial or hospi- IEC 61000-4-8 tal environment. iPS-M S series User Manual V.A1... - Page 31 (>95 % dip in UT) (>95 % dip in UT) another battery. for 5 sec for 5 sec NOTE UT is the a.c. mains voltage prior to application of the test level. iPS-M S series User Manual V.A1...
- Page 32 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2014...
