Mec Micro19 Service & Parts Manual page 41

Secton 13 - Chasss
Item
1
2
3
4
5
6
7
8
9
10
11
12
--
--
--
13
--
--
--
14
15
--
Page 37
Part Number
53263 Screw THMS M04-0.70 × 8
41323 Cover
53313 Nut NNYL M16 × 1.50
53314 WSHR M16 Flat Fender Washer
42414 Wheel
41239 Support
53315 Screw SHCS 3/8-24 × 1 1/4
53316 WSHR 3/8 Spring Washer
53317 WSHR 3/8 Standard Flat Narrow Washer
53268 Screw HHCS M10-1.50 × 30 Serrated Flange
41232 Key
42419 Right Drive Motor Assembly
42886 Right Motor
42889 Brake
42887 Reducer
42421 Left Drive Motor Assembly
42890 Left Motor
42889 Brake
42887 Reducer
53318 Screw PHMS M06-1.00 × 12
42407 Plate
42883 Terminal Connector, Drive Motor Wires
Mcro19 - Servce & Parts Manual
Description
October 2021
Qty.
6
2
2
2
2
2
8
8
8
8
2
1
1
1
1
1
1
1
1
5
1
2
