- Page 1 SBC210LM Portable Rechargeable Battery Housing The Shure portable rechargeable housing, SBC210LM, user guide. Version: 0.1 (2022-D)
-
Page 2: Table Of Contents
Shure Incorporated Table of Contents Optional Accessories SBC210LM Portable Rechargeable Battery Housing Connecting DC Power IMPORTANT SAFETY INSTRUCTIONS Inserting Batteries into the Charging Bay WARNING Charge Status LED Note: Recovering a Battery from Deep Discharge Information to the user Changing the Charger Module... -
Page 3: Sbc210Lm Portable Rechargeable Battery Housing
Shure Incorporated SBC210LM Portable Rechargeable Battery Housing IMPORTANT SAFETY INSTRUCTIONS READ these instructions. KEEP these instructions. HEED all warnings. FOLLOW all instructions. DO NOT use this apparatus near water. CLEAN ONLY with dry cloth. DO NOT block any ventilation openings. Allow sufficient distances for adequate ventilation and install in accordance with the manufacturer’s instructions. -
Page 4: Warning
EMC performance. • Use this battery charger only with the Shure charging modules and battery packs for which it is designed. Use with other than the specified modules and battery packs may increase the risk of fire or explosion. -
Page 5: Information To The User
이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니 다. SBC210LM Portable Rechargeable Battery Housing The SBC210LM's interchangeable charging modules provide a compact desktop charging station for a range of Shure Lithium- ion batteries. 5/11... -
Page 6: Features
Shure Incorporated Features • Interchangeable charging modules for bodypack and handheld transmitter batteries • Charges batteries to 50% capacity in 1.5 hours • Charges batteries to full capacity in 3.5 hours • Modules are compatible with SBC210 portable charger and SBRC rackmount charging station •... -
Page 7: Batteries
SBM920 Charging Module for SB920 and SB920A SBM920 Connecting DC Power Connect the cable from the Shure PS51 power supply to the DC power supply input. The white LED will illuminate when the PS51 is connected to an AC power source. 7/11... -
Page 8: Inserting Batteries Into The Charging Bay
Shure Incorporated Inserting Batteries into the Charging Bay Slide the battery into the charging bay until it locks into place. The charge LED illuminates and the charge cycle begins. Charge Status LED Each charger bay has an LED to indicate the status of the battery. -
Page 9: Troubleshooting
Shure Incorporated Pull the charger module to remove it from the housing. Insert the replacement charger module into the housing (note the orientation of the guide rails). Insert the mounting screws (4 pieces) and tighten them to secure the charging module. -
Page 10: Certifications
Conforms to European Regulation (EC) No. 1275/2008, as amended. CE Notice: Hereby, Shure Incorporated declares that this product with CE Marking has been determined to be in compliance with European Union requirements. The full text of the EU declaration of conformity is available at the following site: https:// www.shure.com/en-EU/support/declarations-of-conformity. - Page 11 REACH (Registration, Evaluation, Authorization of Chemicals) is the European Union (EU) and the United Kingdom (UK) chemical substances regulatory framework. Information on substances of very high concern contained in Shure products in a concentration above 0.1% weight over weight (w/w) is available upon request.
