Parts Replacement Guide
(Image is for illustration purposes only.)
Pride Mobility Products Ltd.
32 Wedgwood Road
Bicester, Oxfordshire OX26 4UL
Telephone: (+44) 1869 324600
Fax: (+44) 1869 323070
Web: www.pridemobility.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quantum Rehab Jazzy Select 6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pride Mobility Quantum Rehab Jazzy Select 6

  • Page 1 Parts Replacement Guide (Image is for illustration purposes only.) Pride Mobility Products Ltd. 32 Wedgwood Road Bicester, Oxfordshire OX26 4UL Telephone: (+44) 1869 324600 Fax: (+44) 1869 323070 Web: www.pridemobility.co.uk...
  • Page 2 Introduction and Warnings Mobility Products. Ltd. Your new Quantum Rehab Parts Replacement Guide has been compiled from the latest product information available at the time of publication. Pride Mobility Products Ltd. reserves the right to make changes and updates to this manual and to ®...
  • Page 3: Table Of Contents

    Table of Contents Mobility Products. Ltd. SECTION I. Shroud Assemblies .................................6 SECTION II. Side Battery Door................................7 SECTION III. Drive Wheel ..................................8 SECTION IV. Solid Tyre ..................................9 SECTION V. Front/Rear Castor Assembly ............................10 SECTION VI. Articulating Beam................................11 SECTION VII. Drive Motor/Front Castor Arm ............................12 SECTION VIII.
  • Page 4 Chair Preparations Mobility Products. Ltd. All of the replacement instructions require safety precautions prior to performing service to the mobility device. These precautions are set in place not only to ensure the safety of the technician but for the end user as well. The replace- ment instructions in the guide will refer back to this section to set-up the product prior to service.
  • Page 5 Seating System Removal Mobility Products. Ltd. Several service applications require the removal of the seating systems. The illustration below outlines the connection point of the seat to the power base. Push Lever Forward Select 6 Seat removal and installation Disengaged Engaged Select 6 with Power Seat removal and installation www.pridemobility.co.uk...
  • Page 6: Shroud Assemblies

    I. Shroud Assemblies Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. Tools Required: - Phillips Screwdriver - Front Electronics Door Removal/Installa- tion: 3. Under the front of the seat, pull up on the front electron- ics door to expose the power module.
  • Page 7: Side Battery Door

    II. Side Battery Door Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. Tools Required: - Flathead Screwdriver - Side Battery Door Removal/Installation: 3. Remove the front electronics cover and the top shroud. See section I. 4.
  • Page 8: Drive Wheel

    III. Drive Wheel Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. 3. Prop up the side of the unit being serviced. Tools Required: - Imperial Socket Set - Calibrated Torque Spanner/Wrench - Phillips Screwdriver 4.
  • Page 9: Solid Tyre

    IV. Solid Tyre Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. 3. Prop up the side of the unit being serviced. Tools Required: - Imperial and Metric Socket Set - Calibrated Torque Spanner/Wrench - Phillips Screwdriver 4.
  • Page 10: Front/Rear Castor Assembly

    V. Front/Rear Castor Assembly Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. 3. Prop up the side of the unit being serviced. Tools Required: - Imperial Socket Set - Imperial Spanner Set - Calibrated Torque Spanner/Wrench - Flathead Screwdriver - Needlenose Pliers...
  • Page 11: Articulating Beam

    VI. Articulating Beam Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. 3. Prop up the rear of the unit. Tools Required: - Metric Socket Set - Metric Spanner Set - Metric Hex Key Set 4.
  • Page 12: Drive Motor/Front Castor Arm

    VII. Drive Motor/Front Castor Arm Assembly Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. 3. Prop up the side of the unit being serviced. Tools Required: - Imperial and Metric Socket Set - Calibrated Torque Spanner/Wrench - Imperial and Metric Hex Key Set - Wire Cutters...
  • Page 13: Freewheel Lever

    VIII. Freewheel Lever Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. 3. Prop up the side of the unit being serviced. Tools Required: - Imperial and Metric Socket Set - Calibrated Torque Spanner/Wrench - Imperial and Metric Hex Key Set - Phillips Screwdriver 4.
  • Page 14: Foot Platform

    IX. Foot Platform Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. Tools Required: - Metric Socket Set - Metric Spanner Set 3. Remove the hardware that connects the footplate height adjustment bracket to the main frame. 4.
  • Page 15: Batteries

    X. Batteries Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. Tools Required: - Metric Socket Set - Metric Spanner Set 3. Removal of the seat may ease the replacement of the batteries. 4.
  • Page 16: Joystick

    XI. Joystick Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. Tools Required: - Phillips Screwdriver - Wire Cutters 3. Disconnect the joystick harness from the bus extension cable that is located near the back of the unit. Cut the cableties to free the joystick cable.
  • Page 17: Power Module

    XII. Power Module Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. Tools Required: - Phillips Screwdriver 3. Remove the front electronics door. See Section I. 4. Remove the screws that secure the power module to the main frame.
  • Page 18: Power Seat Actuator

    XIII. Power Seat Actuator Mobility Products. Ltd. 1. Turn off power to the joystick. 2. Ensure the unit is in drive mode. 3. Disconnect the joystick and all harnesses that connect to the power base. Tools Required: - Imperial and metric Socket Set - Imperial and metric Spanner Set - Imperial and metric Hex Key Set - Phillips Screwdriver...
  • Page 19 Notes Mobility Products. Ltd. www.pridemobility.co.uk...
  • Page 20 (Image is for illustration purposes only.) Pride Mobility Products Ltd. 32 Wedgwood Road Bicester, Oxfordshire OX26 4UL Telephone: (+44) 1869 324600 Fax: (+44) 1869 323070 Web: www.pridemobility.co.uk...
