3.3 Loading the Media

1.
Open the printer top
cover by pulling the
tabs.
3.
Place the roll between
the holders.
5.
Move the media guides
to fit the label width by
pushing the media
guide adjustment
button.
2.
Separate the media holders to
the label roll width.
4.
Place the paper, printing side
face up, through the media
sensor and place the label
leading edge onto the platen
roller.
6.
Gently close the top cover,
using hardware or softeare to
make calibration.(Please refer
to chapter 4&5)
14
