Andamiro HAMMER DX Service Manual

Hide thumbs Also See for HAMMER DX:
Table of Contents

Advertisement

Quick Links

Download this manual
www.andamiro.com
Read the manual before operating this machine.
www.andamirousa.com
Keep this manual for your reference.
ISSUE DATE : NOC. 25, 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HAMMER DX and is the answer not in the manual?

Questions and answers

Related Manuals for Andamiro HAMMER DX

Summary of Contents for Andamiro HAMMER DX

  • Page 1 Read the manual before operating this machine. www.andamirousa.com Keep this manual for your reference. ISSUE DATE : NOC. 25, 2004...

  • Page 2: Precautions For Use

    PRECAUTIONS FOR USE The following safety precautions are given throughout this manual. They must be strictly followed to protect those who install, use or maintain this product as well as to protect players, visitors and property. For safty reasons. • The following suggestions should be adhered to: W A R N I N G Disregarding could result in serious injury.
  • Page 3 PRECAUTIONS FOR USE PRECAUTIONS FOR USE W A R N I N G C A U T I O N W A R N I N G C A U T I O N Be sure to consult an industry specialist when setting Be sure to use indoor wiring within the specified If there is any abnormality such as smoke, Do not use this product anywhere other than...
  • Page 4 PRECAUTIONS FOR USE CONTENTS W A R N I N G C A U T I O N Be sure to turn OFF the main power switch Components in the game are sensitive to and unplug the power cord from the vibrations and impact.

  • Page 5: Specification

    1. Specification and Dimensions 2. Name of Parts DIMENSIONS EXTERNAL PARTS INTERNAL PARTS SPECIFICATION 163 (Watts) POWER CONSUMPTION 29 (Inches) DISPLAY 150 (Kgs) WEIGHT AC 120 / 220 (V), 50~60(Hz) APPROPRIATE POWER SOURCE...

  • Page 6: Monitor Pcb

    Name of Parts Name of Parts 2-2-1. 2-2-3. COIN DOOR AND MONITOR CONTROLER MAIN AND I/O PCB NAME NAME JAMMA X-RECEIVER DIP SWITCH Y-SEND SOUND VOLUME X-SEND IMPACT SENSOR VOLUME TICKET DISPENSER IMPACT SENSOR VOLUME PRIZE 1 Y AXIS SENSOR VOLUME PRIZE1 X AXIS SENSOR VOLUME POWER...

  • Page 7: Connector Connection

    3. How to Assemble CONNECTOR CONNECTION CABINET ASSEMBLY...
  • Page 8 4. Game setup and test mode When you push the TEST S/W, “SETUP 1” is dispalyed as below. You can setup the game as Various setup displays appear each time you push the TEST S/W, as shown in the figure below. you want.
  • Page 9 5. Detailed of setup mode Each designated function in the setup mode can be set by hitting the figure on the screen with your hammer. SETUP 1 • The SETUP 1 display allows you to change coin settings. • You can change the setting values by hitting the “SELECT” button with your hammer as much as you want. •...
  • Page 10 Detailed of setup mode SETUP 2 BONUS TICKET(S) • The degree of difficulty and language of game are set on the SETUP 2 screen. • Set the number of ticket(s) regardless of scores. • You can change the setting values by hitting the “SELECT” button with your hammer as much as •...

  • Page 11: Load Default

    Detailed of setup mode SETUP 3 (Only for the TICKET MODE) LOAD DEFAULT • Setting may be changed for the ticket on the SETUP 3 screen. • All the manufacturer's default setup values can be saved. • You can change the setting values by hitting the “SELECT” button with your hammer as much as you want. •...

  • Page 12: Screen Test

    Detailed of setup mode SCREEN TEST SENSOR SETTING • This display allows you to test CRT status such as display color, etc. • Sets up the exact hit-spot where you hit. • Adjust the exact hit-spot in this display if the actual spot hit and the display spot are different. Setup instructions 1.
  • Page 13 Detailed of setup mode DATA BANK DATA BANK CLEAR • This is mode to ensure information for credit, prize and ticket after the game machine is used. • DATA BANK CLEAR is a mode for deleting the saved values of DATA BANK. •...
  • Page 14 6. A/S MODE You can enter A/S Mode by turning on the power switch with the Test Button pushed. Before getting to this A/S mode, there shoud be nothing on the screen 4) Although all the numbers are "0" and the shock sensor is in a good condition, Sensor problem when the sensor does not in the play you have to change the I/O PCB 5) Reference :...
  • Page 15 A/S MODE Mode for checking Capsule Dispenser Ass’y. 2) When the Capsule Dispenser ass’y does not work, • You can move on to the next Mode by pushing the Test Button as shown below. ( Note : in advance check whether DIP swith is on the prize mode before the following steps ) Hit the screen of figure 2-1 Hit the screen of figure 2-1 Check the motor of the Capsule Dispenser...
  • Page 16 A/S MODE Mode for checking the Ticket Dispenser 2) When the ticket does not work in the game play, You can move on to the next Mode by pushing the Test Button as shown below. ( Note : in advance check whether DIP swith is on the ticket mode before the following steps ) Step#1 : push the button of the ticket dispensor and find if the ticket does not come out, replace the dispensor.

  • Page 17: Troubleshooting

    7. TROUBLE SHOOTING Problem priority STEP 1 STEP 1 CHECK POINTS IN CASE OF NO VIDEO AND NO SOUND If it is no voltage, check the fuse and the disconnection of AC Check the voltage status of input VAC cord If it is O.K., the input VAC and the power until the transformer Check AC lamp in the billboard cabinet is in a good condition.
  • Page 18 TROUBLE SHOOTING 8. OPTION PROBLEMS OF CAPSULE SUPPLYER TICKET DOOR OPTION OPTION 1 OPTION 2 COIN DOOR OPTION OPTION 1 OPTION 2...

  • Page 19: Assembly Drawing And Parts List

    9. DIP S/W Description 10. ASSEMBLY DRAWING AND PARTS LIST 10-1 ASSEMBLING CABINET LOW(1) DIP1 DIP2 DIP3 DIP4 DIP5 DIP6 DIP7 DIP8 CONTENTS IN USE DEBUG MODE NOT IN USE PRIZE MODE MODE TICKET MODE GAME MODE IN USE PAUSE MODE NOT IN USE IN USE...
  • Page 20 ASSEMBLY DRAWING AND PARTS LIST 10-2 10-3 ASSEMBLING CABINET LOW(2) ASSEMBLING CABINET LOW(3) NAME SPEC Q TY CODE NO. NAME SPEC Q TY CODE NO. MONITOR BOARD MHAM0PCB001 TRANSFORMER MELE0TRF016 NAME SPEC Q TY CODE NO. NAME SPEC Q TY CODE NO.
  • Page 21 ASSEMBLY DRAWING AND PARTS LIST 10-4 10-5 ASSEMBLING CABINET LOW(4) ASSEMBLING CABINET UP(1) NAME SPEC Q TY CODE NO. NAME SPEC Q TY CODE NO. CABINET UP MHAT0WOO001 INVERTER MELE0INV003 NAME SPEC Q TY CODE NO. NAME SPEC Q TY CODE NO.
  • Page 22 ASSEMBLY DRAWING AND PARTS LIST 10-7 10-6 ASSEMBLING CABINET UP(2) ASSEMBLING CAPSULE DISPENSER NAME SPEC Q TY CODE NO. NAME SPEC Q TY CODE NO. MAIN BRACKET MHAM0MEP020 GUIDE BRACKET R MHAM0MEP027 MOTOR MMAL0MOT007 ROTATE LOW MHAM0MEP024 NAME SPEC Q TY CODE NO.

  • Page 23: General Wiring Diagram

    11. GENERAL WIRING DIAGRAM...
  • Page 24 12. SCHEMATIC FOR MAIN BOARD...
  • Page 25 SCHEMATIC FOR MAIN BOARD...
  • Page 26 SCHEMATIC FOR MAIN BOARD...
  • Page 27 SCHEMATIC FOR MAIN BOARD...
  • Page 28 SCHEMATIC FOR MAIN BOARD...
  • Page 29 SCHEMATIC FOR MAIN BOARD...
  • Page 30 SCHEMATIC FOR MAIN BOARD...
  • Page 31 13. SCHEMATIC FOR I/O BOARD...
  • Page 33 14. SCHEMATIC FOR MONITOR BOARD...
