6200 Plus/Turbo and 6400/6600/6700 Plus Appliances
DIMM Configuration
The 6200 Plus/Turbo and 6400/6600/6700 Plus appliances have a default memory configuration of
16 GB with two DIMMs in memory slots A1 and B1. You can upgrade to 32 GB. Use the upgrade
procedure below.
16 GB Default Configuration
(front panel of the appliance is at the bottom of the diagram)
To upgrade to
32 GB
32 GB Upgraded Configuration
(front panel of the appliance is at the bottom of the diagram)
Top View
Use DIMMs Procedure
4 x 8 GB Install four 8 GB DIMMs
Top View
6000 and 7000 Appliances Installing and Removing Memory
6000 and 7000 Appliances Replacing Memory | 10
Slots
In all memory slots
