- Page 1 PRT-HPX8-DIN Protege Half DIN Rail 8 Output Expander Installation Manual...
- Page 2 Copyright © Integrated Control Technology Limited 2003-2021. All rights reserved. Last Published: 30-Apr-21 2:58 PM PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual...
-
Page 3: Table Of Contents
New Zealand and Australia European Standards UL and ULC Installation Requirements UL/ULC Installation Cabinet Options ULC Compliance Requirements CAN/ULC-S304 CAN/ULC-S319 UL Compliance Requirements UL1610 UL294 FCC Compliance Statements PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... - Page 4 Industry Canada Statement Disclaimer and Warranty PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual...
-
Page 5: Introduction
900M (3000ft). Further span can be achieved with the use of a network repeater module. The current features of the output expander include: ⦁ RS-485 module communications ⦁ 8 outputs ⦁ Industry standard DIN rail mounting ⦁ Online and remote upgradable firmware PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 6: Installation Requirements
The National Electrical Code, ANSI/NFPA 70 ⦁ The Canadian Electrical Code, Part I, CSA C22.1 ⦁ AS/NZS 2201.1 Intruder Alarm Systems ⦁ The Local Authority Having Jurisdiction (AHJ) ⦁ PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 7: Grounding Requirements
(RS-485 N+, N-, NA, NB) DIN Rail Enclosure Additional DIN Rail Enclosure(s) Controller Reader Expander Dialer’s Earth Ground Connection Input Expander Power Supply Output Expander AC Mains Wiring Earth Ground Link Connection PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... - Page 8 Sector or Building #3 Note that the DIN rail enclosure earth terminal is connected to the power supply V- terminal. There must be only one single earth grounding point per system. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual...
-
Page 9: Mounting
Insert a flat blade screwdriver into the hole in the module tab clip. Lever the tab outwards and rotate the unit off the DIN rail mount. Wiring Diagram PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 10: Dc Power & Encrypted Module Network
RS-485 network cabling. End of Line Resistors: First Module on RS-485 Network Last Module on RS-485 Network 330R 330R From Next Previous Module Module PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 11: Outputs
A suitable isolation circuit must be installed between the relay contacts of the module and the inductive load. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 12: Trouble Inputs
Input Number Description Type Group PXxxx:01-07 Reserved None None PXxxx:08 Module Offline Module Offline System Replace 'xxx' with the appropriate address of the module that you are programming. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 13: Address Configuration
The controller has a set limit on the number of modules of each type that it can support. When adding and configuring modules always refer to the Maximum Module Addresses table in the controller installation manual. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 14: Led Indicators
Incorrect module input voltage applied Output Indicators The output indicators will show the status of the outputs. State Description Constantly on (red) Output is ON Constantly off Output is OFF PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 15: Error Code Indication
The serial number in the device is not valid. Return the unit to the distributor for replacement. Locked Device The module or system controller is a locked device and cannot communicate on the network. Return the unit to the distributor for replacement. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 16: Mechanical Diagram
Relay Output 8 Relay Output 7 Output Indicators Status Indicators Relay Output 5 12VDC Input Relay Output 2 RS-485 Input Relay Output 6 12VDC Pass Through Relay Output 1 PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 17: Mechanical Layout
The mechanical layout shown below outlines the essential details needed to help ensure correct installation and mounting. All measurements are shown in millimeters. 78.40 Front 78.40 39.20 39.20 Back 67.18 PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 18: Technical Specifications
Integrated Control Technology continually strives to increase the performance of its products. As a result these specifications may change without notice. We recommend consulting our website (www.ict.co) for the latest documentation and product information. -
Page 19: New Zealand And Australia
New Zealand and Australia General Product Statement The RCM compliance label indicates that the supplier of the device asserts that it complies with all applicable standards. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 20: European Standards
SP6 (LAN – Ethernet) and DP1 (LAN – Ethernet + PSTN) Tests EMC (operational) according to EN 55032:2015 Radiated disturbance EN 55032:2015 Power frequency Magnetic field immunity tests (EN 61000-4-8) PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... - Page 21 Warning: Enclosures supplied by 3rd parties may not be EN50131-compliant, and should not be claimed as such. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual...
-
Page 22: Ul And Ulc Installation Requirements
Control units that support auto arming shall provide an audible signal throughout the protected area not less than 10 min prior to the auto arming taking place. The control unit shall allow authorized users to cancel PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... - Page 23 The Contact ID Reporting Service must be enabled and the Service Mode must be configured to start with the operating system. Refer to the section Contact ID in the Operator Reference Manual. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual...
- Page 24 Products or components of products, which perform communications functions only, shall comply with the requirements applicable to communications equipment as specified in CAN/CSA-C22.2 No. 60950-1, Information Technology Equipment Safety - Part 1: General Requirements. Where network interfaces, such PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual...
-
Page 25: Can/Ulc-S319
Must be installed with CAN/ULC-S319 listed portal locking device(s) for ULC installations. ⦁ If a flexible cord is used to connect to line voltage, strain relief must be provided for the cord inside the PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 26: Ul Compliance Requirements
Operator Reference Manual. The Trouble Input Area must be armed in 24h mode. Refer to the section Trouble Inputs | Areas and Input Types in the Operator Reference Manual. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... -
Page 27: Ul294
4mm hole in the cabinet to provide external visibility. This shall be wired between 12V and a PGM output that is programmed to follow the AC trouble input as shown below: PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... - Page 28 If a flexible cord is used to connect to line voltage, strain relief must be provided for the cord inside the enclosure or at the knockout. ⦁ The power supply is not intended to be mounted on the exterior of vault, safe, or stockroom. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual...
-
Page 29: Fcc Compliance Statements
NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual... - Page 30 Industry Canada Statement ICES-003 This is a Class A digital device that meets all requirements of the Canadian Interference Causing Equipment Regulations. CAN ICES-3 (A)/NMB-3 (A) PRT-HPX8-DIN | Protege Half DIN Rail 8 Output Expander | Installation Manual...
- Page 31 Integrated Control Technology Ltd nor its employees shall be liable under any circumstances to any party in respect of decisions or actions they may make as a result of using this information. In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice.
- Page 32 Disclaimer: Whilst every effort has been made to ensure accuracy in the representation of this product, neither Integrated Control Technology Ltd nor its employees shall be liable under any circumstances to any party in respect of decisions or actions they may make as a result of using this information. In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice.
