Communication Module DVPSCM12/52-SL
Next: Execute the next command. If the number of the command being executed is one, the number
of the next command which will be executed is two.
Goto: The user can directly designate the command whose number is much larger.
End: The execution of commands comes to an end.
Fail: Designate the action following the execution of a command. The user can choose "Next", "Goto", or
"Abort".
Next: Execute the next command. If the number of the command being executed is one, the number
of the next command which will be executed is two.
Goto: The user can directly designate the command whose number is much larger.
Abort: The execution of commands comes to an end.
Retry: It means the number of times the sending of a command has been retried after the sending fails.
Repeat: It means the number of times the sending of a command has been repeated after the command
has been executed successfully.
Send Wait: The default time interval between the instructions is 0 ms, that is, the next instruction is
transmitted immediately after the reply is received.
Timeout: If there has been no response for a certain period of time after the instruction is transmitted
through the communication port, that period of time is called the communication timeout. The
default communication timeout is 50 ms.
6.3.3

Sequence

The user can click "Add Group" by pressing the right key of the mouse in Sequence to check the groups
which will be executed. These groups will be downloaded as a sequence and executed through the serial
port. In addition, the user can click "Error Execute Group No." twice to set the group which will be executed
when an error occurs. When there is an error in executing a group, the group which is set in "Error Execute
Group No." will be executed.
