Page 2
The power is supplied by the PLC MPU (main processing unit). EN DVPPF02-SL is an OPEN-TYPE device. It should be installed in a control cabinet free of airborne dust, humidity, electric shock and vibration. To prevent...
61131-2 & IEC 68-2-27 (TEST Ea) Components Address Switch The address switches on DVPPF02-SL are used for setting up the node address of DVPPF02-SL on the PROFIBUS DP network. The switches are two rotary switches x16 and x16 .
+A×16 Notes: Set up the address of DVPPF02-SL when the power is off. Re-power the module after you finish setting up the address. Changing the setting of address when DVPPF02-SL is operating is regarded invalid. Use slotted screwdriver carefully to adjust the address in case you scrape the module.
Page 5
2. Open the DIN rail clips on DVPPF02-SL and the PLC MPU. Insert DVPPF02-SL and the PLC MPU on the DIN rail. 3. Clip up the DIN rail clip on DVPPF02-SL and the PLC MPU to fix them on the DIN rail.
Error in parameter Hardware error Configuration error LED Indicators & Trouble-Shooting POWER LED The power LED displays the status of the power supply for DVPPF02-SL. LED status Indication How to correct The power supply is Green light on normal.
Page 7
DVPPF02-SL is in STOP status Operation of Digital Display: 1. When DVPPF02-SL is in normal operation status and the PLC MPU is in RUN status, the digital display will only show its node address. 2. When DVPPF02-SL is in normal operation status and the PLC MPU is in STOP status, the digital display will show its node address and the STOP status code alternately.
Page 16
Bağlantı yapmadan önce ürünün enerjisini kesiniz. Enerji kesildikten sonra 1 dakika boyunca ürünün iç devrelerine müdahale etmeyiniz. DVPPF02-SL ürünü AÇIK TİP bir cihaz olup toz, rutubet, elektrik şoku ve titreşimden uzak kapalı yerlerde muhafaza edilmelidir. Yanlış kullanım sonucu ürünün zarar görmesini önlemek için yetkili olmayan kişiler tarafından ürüne müdahale edilmesini...
A ayarlanır. 26 (decimal) = 1A (hex) = 1×16 +A×16 Notlar: DVPPF02-SL’nin adres ayarı enerji yok iken yapınız. Ayar yaptıktan sonra enerjiyi tekrar veriniz. Çalışma sırasında yapılan DVPPF02-SL adres değişikliği ayarı geçersizdir. Modülün çizilmesini önlemek için adres ayarını uygun bir tornavida yardımıyla dikkatlice yapınız.
Page 18
Kurulum DVPPF02-SL’nin PLC MPU’ya Bağlantısı 1. MPU’daki sol kenar I/O modül bağlantı portu açılır ve DVPPF02-SL ünitesi yanına takılır. İngilizce (English) bölümde Şekil 2 [Figure 2]’de step ’e bakınız. 2. Klipsleri bastırarak bağlantıyı sıkılaştırın. İngilizce (English) bölümde Şekil 2 [Figure ...
Page 19
Konfigurasyon hatası ediniz. DVPPF02-SL’nin bağlı olduğu PLC MPU anahtarını RUN yapınız. PLC MPU STOP durumunda Dijital Display’in Çalışması: 1. DVPPF02-SL normal çalışma durumunda ve PLC MPU RUN konumda ise, dijital gösterge sadece kendi nod adresini gösterecek. - 18 -...
Page 20
2. DVPPF02-SL normal çalışma durumunda ve PLC MPU STOP konumunda ise, dijital gösterge dönüşümlü olarak kendi nod adresini ve STOP durumu kodunu gösterecek. 3. DVPPF02-SL başlama modunda veya hata durumunda ve PLC MPU RUN konumda ise dijital gösterge dönüşümlü olarak kendi nod adresini, başlama veya hata kodunu gösterecek.
