PLEASE READ BELOW BEFORE
PROCEEDING WITH YOUR ASSEMBLY
Unless you're particularly adept at assembling
Flatpack/Knockdown Furniture, we understand building
ready to assemble furniture can be a frustrating
experience for some and you'll probably spend at least half
a day per item. No need to panic, though! Here are some
tips on assembling flat-pack furniture so you're not left
with an impossible Lego project and give up in frustration.
Follow these tips for your item and you'll end up with
beautiful, fully-assembled furniture!
• Do Not throw away packaging material until assembly
is complete.
• Assemble item on a soft surface, such as cardboard or
carpet, to protect finish.
Advertisement
Related Manuals for Furniture of America ID-11424
Summary of Contents for Furniture of America ID-11424
- Page 1 PLEASE READ BELOW BEFORE PROCEEDING WITH YOUR ASSEMBLY Unless you're particularly adept at assembling Flatpack/Knockdown Furniture, we understand building ready to assemble furniture can be a frustrating experience for some and you'll probably spend at least half a day per item. No need to panic, though! Here are some tips on assembling flat-pack furniture so you're not left with an impossible Lego project and give up in frustration.
- Page 2 • Choose a spacious, open area near where the piece will be located. It is easier to move parts than to relocate the furniture after it is fully assembled, depending on its size and weight. • Organize everything and count it twice. If you organize the items by parts, you'll find it much easier to grab each piece as you build.
- Page 6 1) Insert dowels (#C) to holes of panels (#3,4). Align panel (#2) to panels (#3,4), then secure by using screws (#F). Finished side facing down. 2) Attach dowels (#C) and cam bolts (#B) to the holes of panel (#2). Align panel (#1) to the dowels and cam bolts of panel (#2).
- Page 7 1) Attach cam bolts (#B) and dowels (#C) to the holes of panels (#8,9) as shown in the diagram. Distance of panel (#5) to the edge 3) Place stickers (#M) to cover the of panel (#6) is farther. holes of the cam locks (#A). 2) Align panels (#8,9) to the holes of panels (#7) and panels (#5).
- Page 8 Attach cam bolts (#B) and dowels (#C) to the holes of the top panel (#10). Align top panel (#10) to the holes of the base panels as shown in the picture. Secure by using cam bolts (#A). Align back panels (#11,12) to the back of the product.
- Page 9 Align drawer side panels (#16,17) to the drawer back panel (#18). Secure by using screws (#L). Slide drawer bottom panel (#19) through the tin lines of panels (#16,17,18). 1) Align and secure drawer handle (#N) to front drawer panel (#20) by using bolts (#O).
- Page 10 Insert drawers.
- Page 11 Insert shelf pins (#I) to the desired height of the shelves (#15). Insert plugs (#P) and bars (#G) to the holes of the side shelves.
