ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
show the degree of effort needed in assem-
bling a specific product (with 1 being easy and
5 being difficult). For most products, two per-
sons are recommended.
EASY
YNJ-1423-6
TOOLS REQUIRED FOR ASSEMBLY
Allen Wrench
Phillips Screwdriver
Hammer
DIFFICULT
Page 1
2 PERSONS RECOMMENDED
(Included)
(Not Included)
(Not Included)
14-09-09
