MODEL #
CM6268 / CM6368
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PT)
Allen Wrench
(Included)
Wrench
(Included)
2 - People
Recommended
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
Advertisement
Related Manuals for Furniture of America Peever II CM6268
Summary of Contents for Furniture of America Peever II CM6268
- Page 1 MODEL # CM6268 / CM6368 Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PT) Allen Wrench (Included) Wrench (Included) 2 - People Recommended The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 12...
- Page 5 CORNER SOFA CM6268 / CM6368 #1 1pc #2 1pc #3 2pcs #4 2pcs #5 1pc #6 1pc #7 2pcs #8 1pc #9 8pcs #A 2pcs #B 2pcs #C 23pcs #D 27pcs #E 23pcs #F 1pc #G 1pc 5 / 12...
- Page 6 CM6268 CM6368 is packed in 2 cases #A x1pc #B x1pc #C x14pcs CM6268 /CM6368 #D x16pcs #E x14pcs #F x1pc #G x1pc #A x1pc #B x1pc #C x9pcs #D x11pcs #E x9pcs CM6268/CM6368 #F x1pc #G x1pc 6 / 12...
- Page 7 ASSEMBLY INSTRUCTIONS Part #3 x1pc Part #4 x1pc Hardware #A x1pc Hardware #B x1pc Hardware #D x2pcs Hardware #F x1pc Align right armrest support (#4R) to the holes of the right armrest (#3R), then secure by using bolts (#A,B) with washers (#D). Part #1 x1pc Hardware...
- Page 8 ASSEMBLY INSTRUCTIONS Part #5 x 1pc Hardware #C x 6pcs Hardware #D x 6pcs Hardware #E x 6pcs Insert 20% of the threaded studs (#C) into the holes of the backrest (#5). Align the backrest (#5) to the right sofa seat (#1) and the metal brackets of the armrest support, then secure by using hexnut (#E) with washers (#D) to the threaded studs (#C).
- Page 9 ASSEMBLY INSTRUCTIONS Secure corner backrest (#8) to backrest (#5) by Hardware using bolts (#C) with washers (#D) and hex nut (#E). #C x 1pc Hardware #D x 1pc Hardware #E x 1pc Attach pillow (#7R) to the velcro of the armrest (#3R). Part #9 x 4pcs Attach legs (#9) to the bottom holes of the...
- Page 10 ASSEMBLY INSTRUCTIONS Align left armrest support (#4L) to the holes of the left armrest (#3L), then secure by using bolts (#A,B) with Part #2 x1pc washers (#D). Part #3 x1pc Part #4 x1pcs Hardware #A x1pc Hardware #B x1pc Hardware #C x3pcs Hardware #D x5pcs...
- Page 11 ASSEMBLY INSTRUCTIONS Attach pillow (#7L) to the velcro of the armrest (#3L). Part #7 x 1pc Attach legs (#9) to the bottom holes of the left sofa seat (#2). Part #9 x 4pcs 11 / 12...
- Page 12 ASSEMBLY INSTRUCTIONS Align and hook the metal brackets of the sofas together. 12 / 12...
