ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM4630-3PK
DIFFICULT
Page 1 of 7
Tools Required for Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
(Included)
(Not Included)
Rev.14-07-15
Advertisement
Table of Contents
Related Manuals for Furniture of America CM4630-3PK
Summary of Contents for Furniture of America CM4630-3PK
- Page 1 Assembly Instructions CM4630-3PK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3 of 7...
- Page 4 Before you begin, please read Page 3 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 24 pcs Coffee Table Top Bolt 5/16”x50 #B x 24 pcs #2 x 1 pc Lock Washer...
- Page 5 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling the product to avoid any potential injury and/or damage.
- Page 6 #A x 8 pcs Carefully place the coffee table #B x 8 pcs top (#1) facing down on a #C x 8 pcs protected surface. Align the 4 legs (#3) with the pre-drilled holes on the bottom corners of the coffee table top (#1). Prepare 8 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then...
- Page 7 Carefully place the end table top (#4) facing down on a protected surface. Align the legs (#5) with the pre-drilled holes on the bottom corners of the end table top (#4). Prepare 8 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
