LV Furniture B6582-Q-HB Assembly Instruction

Thank you for purchasing this quality product.Be sure to check all packing material carefully for small parts which
may have come loose inside the carton during shipment.Identify and count all parts and compare with hardware
list as below:
STEP 1
(BOX 1) BOX OF HEAD BOARD
ITEM DRAWING DESCRIPTION QTY
HEAD
A 1
BOARD
(BOX 2) BOX OF FOOT BOARD
ITEM DRAWING DESCRIPTION QTY
FOOT
B 1
BOARD
FB
C 2
LEG
LEG SUPPORT FOR
D 2
FB
11
E
SLAT
1
F
CENTER SLAT
6
G
SLATS SUPPORT
(BOX 3) BOX OF SIDE RAILS
ITEM DRAWING DESCRIPTION QTY
SIDE RAIL (L&R)
H 2
(BOX 2) BOX OF FOOT BOARD
(HARDWARE LIST)
ITEM DRAWING DESCRIPTION DIMENSION
C.S.K SCREW
I
4 X 32MM
(M4)
JCBC (M6)
J
6 x P1.0 x 35MM
WITH WASHER
JCBC (M6)
K
6 x P1.0 x 100MM
WITH WASHER
L ALLEN KEY M4
4 x 65MM
M ALLEN KEY M5
5 x 65MM
Screw Driver is not
included
NOTE:MUST TIGHTEN SCREW PERIODICALLY.WITH USE SCREWS WILL
BECOME LOOSE CHECK THIGHT OF ALL SREWS EVERY 6-8 WEEKS.
CLEANING INSTRUCTION
After assembled,clean & polish the complete parts if necessary with soft clotch ang industrial recognized furniture polish.
A
SSEMBLY
MODEL:B6582-Q-HB, B6582-Q-FBD,B6582-KQ-RAIL
B
D
C
D
Affix the Leg Support (D) to Foot
Board (B) as shown. Loosen or
tighten Leg Support (D) as necessary
to level the bed.
QTY
STEP 2
6
3
2
1
1
B
I
NSTRUCTIONS
C
B
C
K
L
Attach and tighten the FB leg
(C) to the Foot Board (B), insert
JCBC (M6) With Washer (K) as
shown.
B
D
H
COMPLETED
ASSEMBLY
Page 1 of 2
MADE IN MALAYSIA
