ASSEMBLY INSTRUCTION
Thank you for purchasing this quality product.Be sure to check all packing material carefully for small parts that may have come loose inside the carton during
shipment.
HARDWARE LISTS
NO
DESCRIPTION
JCBB
A
Ø8 x 25mm
JCBB**
B
Ø8 x 40mm
JCBC
C
Ø6 x 16mm
CSK Screw
D
Ø3.5 x 16mm
EXAMPLE FOR SKETCH ONLY
QTY
NO
DESCRIPTION
CSK Screw
12
E
Ø4 x 38mm
Allen Key
2
F
M4
Allen Key
G
6
M5
*JCBB assembled on third legs.
2
NO
DESCRIPTION
1
Headboard
2
Footboard
QTY
8
1
1
3
4
LV-2016-185 Double/Queen/King Bed
COMPONENT LISTS
QTY
NO
DESCRIPTION
1
5
1
6
Side rail
2
7
Third leg
2
QTY
Centre rail
1
Cross bar
1
Slat base
11
MADE IN MALAYSIA
PAGE 1 OF 4
Advertisement
Table of Contents
Related Manuals for LV Furniture LV-2016-185
Summary of Contents for LV Furniture LV-2016-185
- Page 1 ASSEMBLY INSTRUCTION LV-2016-185 Double/Queen/King Bed Thank you for purchasing this quality product.Be sure to check all packing material carefully for small parts that may have come loose inside the carton during shipment. COMPONENT LISTS DESCRIPTION DESCRIPTION Headboard Centre rail Footboard...
- Page 2 ASSEMBLY INSTRUCTION LV-2016-185 Double/Queen/King Bed STEP 2 STEP 1 Place the Cross Bar in between the Side Rails at front as Pre-screw JCBB screw into position on Headboard and shown. Use allen key to tigthen the JCBC screws from Footboard as shown. Hook the side rail to the JCBB Cross Bar to Side Rails until the screws are totally in.
- Page 3 ASSEMBLY INSTRUCTION LV-2016-185 Double/Queen/King Bed STEP 3 STEP 4 Place centre rail as shown. Use allen key to tighten Use screwdriver to tighten the CSK Screws from the JCBC Screws from Centre Rail to Cross bar until Centre Rail to Footboard until the Screws are totally the Screws are totally in.
- Page 4 ASSEMBLY INSTRUCTION LV-2016-185 Double/Queen/King Bed STEP 5 STEP 6 Place the third leg under centre rail as shown and use Place Slat Base on Side Rail Support and fix CSK allen key to tighten the JCBB screws until they are totally Screws at the holes as shown.
