ASSEMBLY
INSTRUCTION
2.5 hrs
APPROXIMATE ASSEMBLY TIME
EXCLUDING GLUE SETTING TIME
8 m m
f
REQUIRED ASSEMBLY TOOLS
210 mm
210 mm
502 mm
DESCRIPTION:
Type 319
BOOM
2 PERSON ASSEMBLY
1940 mm
1400 mm
FLOOR AREA
2,5M X 2,5M
REQUIRED ASSEMBLY SPACE
M E A
S U R
E
ASSEMBLED DIMENSIONS
PACK 1
CONSISTS OF PARTS :
1, 2, 3, 4, 6, 8, 9, 11.
Fittings
PACK 2
CONSISTS OF PARTS :
5, 7, 10, 13, 14, 15, 16.
2144 mm
CEILING HEIGHT
2,0M
1/16
