Utility
Installation Guide
For Model:
UT56
net weight of fan: 11.68 lb (5.3 kg)
READ THESE INSTRUCTIONS AND
AND SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 6
Warranty. pg. 8
page 1
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UT56 and is the answer not in the manual?

Questions and answers

Related Manuals for Craftmade UT56

Summary of Contents for Craftmade UT56

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND AND SAVE THEM FOR FUTURE USE Utility Installation Guide For Model: UT56 Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 Parts Inventory. pg. 3 Installation Preparation. pg. 4 Hanging Bracket Installation. pg. 4 Fan Assembly.

  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that the hanging location allows the 10 feet inches blades a clearance of 10ft. (3.05m) from the (3.05 m) (76 cm) floor and 30in. (76cm) from any wall or obstruction.

  • Page 5: Fan Assembly

    5. Fan Assembly. Loosen canopy set screw and lower canopy to expose hanging bar. Separate electrical wiring and safety cable from rubber band. Lift fan onto j-hook hanging bracket and slide rubber bushing over j-hook hook. Make the wiring connections as hanging bracket shown in Section 6 on the following page.

  • Page 6: Wiring

    wall control wire 6. Wiring. wood joist from ceiling safety cable CAUTION: Be sure outlet box is properly black grounded and that a ground wire (GREEN or white wood screw Bare) is present. and washer Make sure all electrical connections comply with Local Codes or Ordinances and the National Electrical Code.

  • Page 7: Canopy Assembly

    8. Canopy Assembly. Lift canopy until it covers hanging bracket and touches ceiling. Tighten canopy set screw to secure canopy. canopy canopy set screw 9. Blade Assembly. WARNING: To reduce the risk of serious bodily injury, DO NOT use power tools to assemble the blades. If screws are overtightened, blades may crack and break.

  • Page 8: Testing Your Fan

    Service at 1-800-486-4892 to arrange for return of fan. Return fan, shipping prepaid, to Craftmade. We will repair or ship you a replacement fan, and we will pay the return If fan does not function, please refer to shipping cost.
