Hamilton Desk
L5131
Assembly Difficulty
two person job
easy -
medium
- hard
Thank you for shopping with GLTC, we hope you enjoy
having this product in your home.
We know assembling furniture, toys or accessories is not everyone's
favourite way to spend their time, so we've tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you'll sail
through the whole process. But if it all feels a bit too much
like hard work, then we do have an assembly company we
can recommend: the Flatpack Construction Company offers a
nationwide service and can be contacted on 0843 289 4951 or
www.flatpackconstruction.co.uk.
A few important pointers before you start:
•
Please read the instructions right through before you start, and check
that all the components have been included in the pack; we find
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
•
Make sure you have the right tools. Allen keys are provided if required,
but screw drivers and other tools are not. You'll find details of the tools
you need at the beginning of the instructions.
•
Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts or hardware.
V1
19/11/2020
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Great Little Trading Hamilton L5131
Summary of Contents for Great Little Trading Hamilton L5131
- Page 1 Thank you for shopping with GLTC, we hope you enjoy having this product in your home. We know assembling furniture, toys or accessories is not everyone’s favourite way to spend their time, so we’ve tried to make assembling this item as quick and painless as possible. Hopefully our efforts will have been worthwhile and you’ll sail Hamilton Desk through the whole process.
-
Page 2: Safety Warnings
Safety Warnings: Customer Service: • PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. • If you find that any components are missing or damaged, please do not begin assembly and do not use the item. Please contact GLTC • Adult assembly required. Customer Services on 0344 848 6000 immediately. -
Page 3: Component Checklist
Component Check List Component Check List Desk Base Panel 1x Desk Back Panel 1x Drawer - Front Panel 1x Drawer - Front Panel Hardware Check List 1x Central Divider Panel 1x Leg Side Panel 24x Cam Dowels 9x Bolts (67mm) 1x Leg Cross Bar 1x Leg Side Panel 9x Barrel Nuts... - Page 4 Hardware for Step 2: Hardware for Step 1: 3x #2 Bolts (67mm) 2x #1 Cam Dowels 3x #3 Barrel Nuts 2x #4 Wooden Dowels STEP 1: STEP 2: Working on a protective surface such as a carpet or rug, take desk base panel A Insert 3x barrel nuts (#3) into the 3 central holes along the back edge of panel and position with the all drill holes facing up.
- Page 5 Hardware for Step 3: STEP 4: Insert 2x cam dowels (#1) into the holes as shown on BOTH leg side panels D & Using Cam Locks: 2x #4 Wooden Dowels When inserting into the panel, ensure that each cam lock’s arrow is pointing towards the drill hole on the side edge of the panel 2x #5 Cam Locks...
-
Page 6: Step 5: Attach The Legs
STEP 6: STEP 5: Attach the legs Hardware for Step 6: Repeat step 5 using the 2nd leg side panel E. Position the assembled panels so they are resting on the back panel B as shown. 2x #2 Bolts (67mm) Insert 2x barrel nuts (#3) into back panel B, next to the edge you are attaching the first Ensure that bolt hardware #2 is fully tightened on set of legs to. - Page 7 STEP 7: STEP 8: Hardware for Step 7: Hardware for Step 8: Take desk top panel G and position with all drill Carefully stand the partially build desk onto its feet. holes facing up. 2x #2 Bolts (67mm) Insert 6x wooden dowels (#4) partially built into the inner 8x #1 Cam Dowels holes on the top edges of leg panels D&E and central divider panel C.
- Page 8 STEP 9: STEP 10: Create the drawers Hardware for Step 9: Hardware for Step 10: Take back upstand H and insert 2x cam dowels Take 2x panel J and 2x panel I and orientate with the (#1) to the two holes on the long flat side. groove and holes facing up.
- Page 9 STEP 11: STEP 12: Hardware for Step 12: Hardware for Step 11: Fix the 2x handles (#9) to drawer fronts M & N using Insert 2x wooden dowels (#4) into the outer 4x short bolts (#8). holes of the open ends of the four drawer box sides (2xI &...
- Page 10 Insert both drawers into the desk frame. Your desk is now ready to use. Please note the position of each drawer as shown. Copyright© 2021 G.L.T.C. Ltd. All rights reserved. Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
