Loxley Storage Cupboard
L5013
Assembly Difficulty
easy - medium
- hard
two-person job
Thank you for shopping with GLTC, we hope you enjoy
having this product in your home.
We know assembling furniture, toys or accessories is not everyone's
favourite way to spend their time, so we've tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you'll sail
through the whole process. But if it all feels a bit too much
like hard work, then we do have an assembly company we
can recommend: the Flatpack Construction Company offers a
nationwide service and can be contacted on 0843 289 4951 or
www.flatpackconstruction.co.uk.
A few important pointers before you start:
•
Please read the instructions right through before you start, and check
that all the components have been included in the pack; we find
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
•
Make sure you have the right tools. Allen keys are provided if required,
but screw drivers and other tools are not. You'll find details of the tools
you need at the beginning of the instructions.
•
Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts or hardware.
V1
20/07/2020
1
Advertisement
Table of Contents
Related Manuals for Great Little Trading Loxley L5013
Summary of Contents for Great Little Trading Loxley L5013
- Page 1 Thank you for shopping with GLTC, we hope you enjoy having this product in your home. We know assembling furniture, toys or accessories is not everyone’s favourite way to spend their time, so we’ve tried to make assembling this item as quick and painless as possible. Hopefully our efforts will have been worthwhile and you’ll sail Loxley Storage Cupboard through the whole process.
-
Page 2: Safety Warnings
Safety Warnings: Customer Service: • Adult assembly required. • If you find that any components are missing or damaged, please do not begin assembly and do not use the item. Please contact GLTC • In an unassembled state product contains small parts which may pose Customer Services on 0344 848 6000 immediately. -
Page 3: Component Checklist
Component Check List Component Check List Cam Locks Cam Dowels 1x Side Panel 1x Side Panel Wooden Dowels 2x Wooden Handles 1x Mid Shelf 1x Top Shelf 2x Handle Bolts Door Screws (18mm) (12mm) Bolts 1x Magnet Catch (25mm) 1x Lower Back Panel 1x Upper Back Panel Back panel Screws 2x Screw... - Page 4 STEP 2: Hardware for Step 1: Using a phillips screwdriver, insert 4x Cam dowels (#2) into the outer drill holes of BOTH panel A and B. 1x #8 Magnet Catch Hardware for Step 2: 2x #9 Screws (15mm) 8x #2 Cam Dowels STEP 1: Take Mid Shelf panel D and attach the magnet catch (#8) using 2x 15mm screws (#9).
- Page 5 STEP 3: STEP 4: Hardware for Step 3: Hardware for Step 4: You will be building this unit with the back on the floor. Insert 6x wooden dowels (#3) into the remaining small The back edges of the panels will have a groove or pilot holes on panel B as shown.
- Page 6 STEP 5: Hardware for Step 5: Hardware for Step 6: Insert 4x cam dowels (#2) into the outer holes of base panel G as shown. Then insert 4x wooden dowels (#3) into the inner 4x #1Cam Locks 4x #3 Wooden Dowels holes.
- Page 7 STEP 7: STEP 8: Hardware for Step 7: Hardware for Step 8: With the help of a second person, carefully turn the With the help of a second person, carefully stand unit over. the unit on its feet. Position lower back panel F in the cupboard section Insert the hinge sets into each side of the unit.
- Page 8 Repeat with door I. NOTE: You need to fix the hardware on one door before moving to the next one. #6 x2 Copyright© 2020 G.L.T.C. Ltd. All rights reserved. Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
