Greenaway Freestanding Bookcase
L5009
Assembly Difficulty
easy
- medium - hard
one-person job
Thank you for shopping with GLTC, we hope you enjoy
having this product in your home.
We know assembling furniture, toys or accessories is not everyone's
favourite way to spend their time, so we've tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you'll sail
through the whole process. But if it all feels a bit too much
like hard work, then we do have an assembly company we
can recommend: the Flatpack Construction Company offers a
nationwide service and can be contacted on 0843 289 4951 or
www.flatpackconstruction.co.uk.
A few important pointers before you start:
•
Please read the instructions right through before you start, and check
that all the components have been included in the pack; we find
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
•
Make sure you have the right tools. Allen keys are provided if required,
but screw drivers and other tools are not. You'll find details of the tools
you need at the beginning of the instructions.
•
Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts or hardware.
V1
20/07/2020
1
Advertisement
Table of Contents
Related Manuals for Great Little Trading Greenaway L5009
Summary of Contents for Great Little Trading Greenaway L5009
- Page 1 Thank you for shopping with GLTC, we hope you enjoy having this product in your home. We know assembling furniture, toys or accessories is not everyone’s favourite way to spend their time, so we’ve tried to make assembling this item as quick and painless as possible. Hopefully our efforts will have been worthwhile and you’ll sail Greenaway Freestanding Bookcase through the whole process.
- Page 2 Safety Warnings: Customer Service: • Adult assembly required. • If you find that any components are missing or damaged, please do not begin assembly and do not use the item. Please contact GLTC • In an unassembled state product contains small parts which may pose Customer Services on 0344 848 6000 immediately.
- Page 3 Component Check List Component Check List 14x Cam Locks 18x Cam Dowels (12mm H) 1x Side Panel 1x Side Panel 14x Wooden Dowels 4x Cam Locks (9mm H) 1x Upper Back Panel 1x Front Panel 18x Back Panel Screws 1x Anti Tip Kit (20mm) You will need (not supplied)
- Page 4 Hardware for Step 1: Hardware for Step 2: 2x #2 Cam Dowels 2x #1Cam Locks (12mmH) 2x #4 Wooden Dowels Using Cam Locks: When inserting into the panel, ensure that each cam lock’s arrow is pointing towards the drill hole on the side edge of the panel &...
- Page 5 STEP 4: Hardware for Step 4: Insert 6x wooden dowels (#4) into the remaining small Hardware for Step 3: holes on panel A. Firstly take the joined panels D/F and connect to panel A 6x #1 Cam Locks (12mmH) at the square base end. Note the orientation - the legs of panel D should be on the smooth front edge of panel A, 16x #2 Cam Dowels next to the large drill holes.
- Page 6 STEP 5: STEP 6: Insert 3x wooden poles (I) into the large drill holes of panel A. Insert 6x wooden dowels (#4) into the central holes in the edges of panels C, E, E & F plus the 2 holes in panel D. Now take panel B (with hardware already inserted) and align over the bookcase panels constructed and the wooden poles.
- Page 7 So complete the application of the anti-tip kit as per the instructions provided. Copyright© 2020 G.L.T.C. Ltd. All rights reserved. Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
