Fishing Vessel Specifications
The purpose of this manual is to provide the operating procedures for the functions available with
the fishing vessel specifications models (50 kW and 60 kW models) of the FAR-2107/FAR-2807
series radar. This manual is provided in addition to the Operator's Manual, which covers features
common to all radars in this radar series.
Specification type is set during installation. For details, contact a FURUNO agent or dealer.
Operation from the menu involves spinning the scrollwheel to select menu item or option then
pushing the scrollwheel or left button to confirm selection. For sake of brevity, we write "Select
XXX" (XXX=name of menu item) when you would spin the scrollwheel to make a selection and
"push the left button" when you confirm selection.
Contents
1. TARGET TRAIL FUNCTIONS................... 2
1.1 Long Trails.................................................... 2
1.2 Trail Color..................................................... 3
1.3 Trail Color Shift............................................. 4
1.4 Hiding Trails ................................................. 5
1.5 Trail Eraser................................................... 6
1.6 Narrow Trails ................................................ 7
2. CURSORS ................................................. 8
2.1 Crosshairs Cursor Size ................................ 8
2.2 Net Cursor .................................................... 9
2.3 Cursor Data Display ................................... 11
2.4 Bearing Scale Format................................. 12
3. OTHER FUNCTIONS............................... 13
3.1 Echo Display Area...................................... 13
3.3 Radar Picture Color.................................... 15
3.4 Bearing Reference ..................................... 16
3.5 VRM, Cursor Unit ....................................... 17
3.6 Pop-up Guidance ....................................... 17
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
FAR-2107/FAR-2807 SERIES
www.furuno.co.jp
MARINE RADAR
Operator's Manual:
4. FUNCTION KEYS (F1 - F4) .....................18
4.1 F1, F2 and F3 Keys.................................... 18
4.2 Operating the F4 Key ................................. 27
5. ANCHOR WATCH ALARM......................31
6.2 Mark Settings ............................................. 33
6.3 Track Settings ............................................ 36
6.4 GPS Buoy .................................................. 41
7. ARP SYMBOLS .......................................42
EXTERNAL RADAR ................................43
9. MENU TREE.............................................44
