Introduction

1 Introduction
1.1

General Description and Use

WARNING: The High Flow
its intended purpose or beyond the scope of its specifications.
warning can result in personal injury or damage to the equipment. For details on
appropriate use, refer to the general description, application, and operation discussions
in this manual.
WARNING: The High Flow
personal protection of the user or others.
The Hi Flow
designed to determine the rate of gas leakage around various pipe fittings, valve
packings, and compressor seals found in natural gas transmission, storage, and
compressor facilities.
The Hi Flow
rate to capture all the gas leaking from the component along with a certain amount of
surrounding air. By accurately measuring the flow rate of the sampling stream and the
natural gas concentration within that stream, the gas leak rate can be calculated using
Equation 1. The instrument automatically compensates for the different specific gravity
values of air and natural gas, thus assuring accurate flow rate calculations.
Leak = Flow x (Gas
where:
To ensure that the instrument is capturing all the gas that is escaping from the
component, two measurements are performed at two different flow rates. The first
measurement is taken at the highest possible flow rate, followed by a second
measurement at a flow rate that is approximately 70–80% of the first. If the two
calculated leak rates are within 10% of each other, then it can be assumed that all gas
has been captured during the test.
CAUTION: Additional precautions and considerations are required when using the
instrument in natural gas streams of mixed composition. Refer to section 2.1 for
guidelines.
The instrument is packaged inside a backpack, thus leaving the operator's hands free for
climbing ladders or descending into a confined space.
The instrument is packaged inside a backpack, thus leaving the operator's hands free for
climbing ladders or descending into tight spaces.
The instrument is controlled by a handheld Control Unit consisting of an LCD and a 4-key
touch pad, which is attached to the main unit via a 6 foot coiled cord. The Control Unit
comes with two magnets which can be easily attached to a steel pipe, regulator box or
compressor for easy viewing. Alternately, the Control Unit can be used in conjunction
with the neck strap accessory.
Instruction 0055-9017

Sampler is not to be used in any application that is beyond

Sampler is not to be used as a safety device for the

Sampler is a portable, intrinsically safe, battery-powered instrument

Sampler determines a component's leak rate by sampling at a high flow
– Gas
sample background
Leak = rate of gas leakage from source (cfm)
Flow = sample flow rate (cfm)
Gas = concentration of gas from leak source (%)
sample
Gas = background gas concentration (%)
background
–2
) x 10

Hi Flow Sampler
Failure to follow this
Eq. 1
