Kramer WAV-6UAB Quick Start Manual

Congratulations on purchasing your Kramer Wall Plate / Wall Plate Insert!
The WAV-6UAB is a one gang
wall plate insert that has one
USB connector (type A) at the
front and a cable with a USB
connector (type B) connector at
the rear. In addition, the
WAV 6UAB has pass through
connectors for:
Computer graphics video
"PC" on an HD15
connector and
unbalanced stereo audio
on a 3.5mm mini plug
connector
Video (composite or SDI)
on a yellow RCA
connector and
unbalanced stereo audio
on RCA connectors
(white for L and red for R)
The WAV-6UBA is a one gang
wall plate insert that has one
USB connector (type B) at the
front and a cable with a USB
connector (type A) connector at
the rear. In addition, the
WAV-6UBA has pass through
connectors for:
Computer graphics video
"PC" on an HD15
connector and
unbalanced stereo audio
on a 3.5mm mini plug
connector
Video (composite or SDI)
on a yellow RCA
connector and
unbalanced stereo audio
on RCA connectors
(white for L and red for R)
The WU-AA is a single insert wall plate with one USB connector (type A) at the front
and a cable with a USB connector (type A) connector at the rear.
The WU-AB is a single insert wall plate with one USB connector (type A) at the front
and a cable with a USB connector (type B) connector at the rear.
The WU-BA is a single-insert wall plate with one USB connector (type B) at the front
and a cable with a USB connector (type A) connector at the rear.
The WU-BB is a single-insert wall plate with one USB connector (type B) at the front
and a cable with a USB connector (type B) connector at the rear.
