INSTALLATION MANUAL
GPS NAVIGATOR
GP-90
1. EQUIPMENT LIST ............................................................................................ 1
2. DISPLAY UNIT .................................................................................................. 2
3. ANTENNA UNIT ................................................................................................ 3
4. WIRING ............................................................................................................. 5
5. INITIAL SETTINGS ........................................................................................... 7
6. OPTIONAL DGPS ........................................................................................... 18
7. TAPING ANTENNA UNIT GPA-018S ............................................................. 19
PACKING LISTS & INSTALLATION MATERIALS........................................... A-1
OUTLINE DRAWINGS ...................................................................................... D-1
INTERCONNECTION DIAGRAM ......................................................................S-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Furuno GP-90

Summary of Contents for Furuno GP-90

  • Page 1 Back INSTALLATION MANUAL GPS NAVIGATOR GP-90 1. EQUIPMENT LIST ... 1 2. DISPLAY UNIT ... 2 3. ANTENNA UNIT ... 3 4. WIRING ... 5 5. INITIAL SETTINGS ... 7 6. OPTIONAL DGPS ... 18 7. TAPING ANTENNA UNIT GPA-018S ... 19 PACKING LISTS &...
  • Page 2 SAFETY INSTRUCTIONS WARNING Do not work inside the equipment unless totally familiar with electrical circuits. Hazardous voltage which can cause electrical shock, burn or serious injury exists inside the equipment. Turn off the power at the mains switchboard before beginning the installation. Post a sign near the switch to indicate it should not be turned on while the equip-...

  • Page 3: Equipment List

    EQUIPMENT LIST Standards Name Type GPA-017S Antenna Unit GPA-018S GPA-019S GP-90-N Display Unit GP-90-A Installation CP20-01900 Materials CP20-01950 Spare Parts SP20-00500 Options Name Flush Mount Kit S OP20-24 Flush Mount Kit F OP20-25 CP20-01700 CP20-02700 Antenna Cable Set CP20-01710 CP20-02710 Antenna Cable Assy.

  • Page 4: Display Unit

    DISPLAY UNIT The display unit can be installed with either of four methods as shown below. Refer to the outline drawing at the end of manual. Locate the unit away from exhaust pipes and vents. The mounting location should be well ventilated. Mount the unit where shock and vibration are minimal.

  • Page 5: Antenna Unit

    ANTENNA UNIT Mounting Install the antenna unit referring to the installation diagram at end of manual. When selecting a mounting location for the antenna unit, keep in mind the following points. Select a location out of the radar beam. The radar beam will obstruct or prevent reception of the GPS satellite signal.
  • Page 6 3. ANTENNA UNIT How to attach the N-P-8DFB connector Outer Sheath Armor Inner Sheath Shield Cover with heat-shrink tubing and heat. Clamp Gasket (reddish brown) Trim shield here. Insulator Trim aluminum tape foil here. Clamp Nut Solder through the hole. Remove outer sheath and armor by the dimensions shown left.

  • Page 7: Wiring

    WIRING The figure below shows the connection of cables on rear of display unit. Antenna Unit GPA-019S GPA-018S GPA-017S 20cm External Equipment CAUTION Ground the display unit to prevent loss of sensitivity and mutual interference. Rear of Display Unit DATA1 DATA2 DATA3 DATA4...
  • Page 8 4. WIRING Grounding The display unit contains several CPUs. While they are operating, they radiate noise, which can interfere with other radio equipment. Ground the unit as follows to prevent it. The grounding wire should be 1.25sq or larger. The grounding wire should be as short as possible. External Equipment The DATA1, DATA2, and DATA3 ports are used to connect an external equipment such as autopilot, remote display, navigation equipment.

  • Page 9: Initial Settings

    The beacon receiver (GR-7000A) can automatically select optimum reference station by feeding GP-90’s position data. If it takes more than 5 minutes to fix DGPS position at the automatic mode, switch to manual mode. Use the manual mode when an external beacon receiver has no automatic function of station selection.

  • Page 10: Manual Dgps Setup

    5. INITIAL SETTINGS 5. Press the [NU/CU ENT] key. 6. Press the [MENU ESC] key. Manual DGPS setup Enter four digit ID number, frequency and baud rate of station. 1. Press [MENU ESC], [9] and [7] to display the DGPS SETUP menu. 2.
  • Page 11 You can convert a Loran Plotter to a GPS Plotter with position data from the GP-90. Before selecting data to output, confirm what data the external equipment requires. Output necessary data only.
  • Page 12 5. INITIAL SETTINGS Data format and data output availability Output data sentence of IEC 61162-1 and NMEA 0183 Ver. 1.5/2.0. AAM: Waypoint arrival alarm APB: Autopilot sentence B magnitude of cross track error, direction to steer, arrival alarm, bearing to waypoint ("Heading to steer to destination waypoint data"...
  • Page 13 DPT: Depth HDG: Heading, deviation and variation HDM: Heading, magnetic HDT: Heading, true MTW: Water temperature TLL: Target latitude and longitude VBW: Dual ground/water speed VHW: Water speed and heading. FURUNO proprietary sentence AGFPA: Autopilot information from FURUNO autopilot equipments.
  • Page 14 Note: Output data should be less than 100%. When the external equipment cannot display correct data input from the GP-90, the rate of operation should be lowered. For example, set a rate of operation less than 60 % for the Temperature Indicator TI-20.
  • Page 15 DATA 1 output setting 1) Press [MENU], [9] and [3]. The DATA 1, 3 OUTPUT SETUP menu appears. Data Fmt. Output Data DATA3. Log Pulse ENT : Enter Figure 5-3 DATA 1, 3 OUTPUT SETUP menu 2) Press to select Data Fmt. 3) Press to select V1.5, V2.0 or IEC.

  • Page 16: Data 2 Output Setting

    5. INITIAL SETTINGS DATA 2 output setting 1) Press [MENU], [9] and [4]. The DATA 2 OUTPUT SETUP menu appears. Data Fmt. Output Data ENT : Enter Figure 5-4 DATA 2 OUTPUT SETUP menu 2) Follow the procedure for setting DATA 1 output. DATA 3 output setting The DATA 3 can output NMEA 0183 (V1.5/V2.0) /IEC 61162-1 data or log pulse by selecting inner jumper wires.
  • Page 17 Setting DATA 4 to Data Output 1) Press [MENU], [9] and [5]. The DATA 4 I/O SETUP menu appears. DATA 4. Level To Next Page ENT : Enter Figure 5-5 DATA 4 I/O SETUP menu 2) Press to select DATA4. Level. 3) Press to select level of external equipment;...
  • Page 18 5. INITIAL SETTINGS Setting DATA 4 to “COM.” (general data) Waypoints and Routes data can be received from a personal computer, through the DATA 4 port. 1) Press [MENU], [9] and [5]. 2) Press to select DATA4. Level. " 3) Press to select level of personal computer;...
  • Page 19 15) Press the [ESC] key. Setting DATA 4 to DGPS An external DGPS receiver can be connected to the DATA 4 port. Follow the procedure below to setup the GP-90 according to the specifications of the DGPS receiver. 1) Press [MENU], [9] and [5].

  • Page 20: Optional Dgps

    RS-422* TD-B RD-A RD-B NP Board Open When the GP-90 is connected with Beacon Receiver GR-80, do the setting as follows. Signal level First Bit Parity Stop Bit Baud Rate *1: Coincide with the setting of the Beacon Receiver GR-80.

  • Page 21: Taping Antenna Unit Gpa-018S

    TAPING ANTENNA UNIT GPA-018S After inserting the whip antenna to the antenna base of GPA-018S, tape the antenna base and whip antenna with self-vulcanizing tape and vinyl tape to reinforce the whip antenna. 1. Wrap the antenna junction point with butyl 15 tape or the equivalent. How to wrap 1) Pull the tape to be about two times in length and wind it up, overlapping by 1/2 the width of the tape.
  • Page 24 OUTLINE DESCRIPTIONS NJ-TP-3DXV-1 CODE 000-123-809-00 NO360 0.2X19X10000 CODE 000-835-215-00 N-P-8DFB-CF CODE 000-156-918-10 Uﾃｰﾌﾟ 0.5X19X5M Uﾃｰﾌﾟ 0.5X19X5M 000-165-833-10 CODE 000-800-985-00 CODE NO. TYPE GP-80,GP-90,SC-55,GP-3500/F,GP- 1850,GP-1650,FA-100,FA-150,GP- 1640/F,SC-60/120,GD/GP- 型名／規格 略  図 OUTLINE DESCRIPTIONS 8D-FB-CV *30M* CODE 000-111-547-00 8D-FB-CV *50M* CODE 000-117-599-00 004-372-420-00 20AG-X-9405 CP20-01701 数量 用途／備考...
  • Page 25 CODE 000-123-809-00 NO360 0.2X19X10000 CODE 000-835-215-00 N-P-8DFB-CF CODE 000-156-918-10 TNCP-NJ CODE 000-156-599-10 Uﾃｰﾌﾟ 0.5X19X5M Uﾃｰﾌﾟ 0.5X19X5M 000-165-833-10 CODE 000-800-985-00 CODE NO. TYPE GP-80,GP-90,SC-55,GP-3500/F,GP- 1850,GP-1650,FA-100,FA-150,GP- 1640/F,SC-60/120,GD/GP- 型名／規格 略  図 OUTLINE DESCRIPTIONS 8D-FB-CV *30M* CODE 000-111-547-00 8D-FB-CV *50M* CODE 000-117-599-00 004-381-190-00 20AX-X-9401 CP20-02701 数量 用途／備考...
  • Page 30 Sep.29'05...
  • Page 31 Feb. 19, '03...
  • Page 32 Feb. 19, '03...
  • Page 34 TNC-P-3 N-J-3 N-P-8DFB 0.2m NJ-TP-3DXV,1m 0.2m または TNCP-NJ...
  • Page 36 Printed in Japan All rights reserved. All rights reserved. Pub. No. IME-44270-C1 Pub. No. IME-44270-C1 ( ( HIMA HIMA ) ) GP-90 GP-90 The paper used in this manual is elemental chlorine free. FURUNO Authorized Distributor/Dealer FURUNO Authorized Distributor/Dealer FIRST EDITION : FIRST EDITION :AUG.
