Sun Microsystems Rack Service Manual page 8

FIGURE 1-1
TABLE 1-1
Rack Terminal
Rear Left
Rear Right
Front Left
2 Sun Rack Service Manual • November 2002
1
2
3
7
8
9
Front of Rack
Top View of Rack Frame Showing Grounding Strap Terminals
Grounding Strap Connections
Grounding
Strap
Number
1
2
3
4
5
6
7
8
9
4
5
6
10
11
12
Connected to:
Left extension panel
Left side panel
Rear door if hinged on left
Right extension panel
Top panel
Rear door if hinged on right
Front door if hinged on left
not used
not used
