Middle Atlantic Products C5 Series Instruction Sheet
Flip-up side shelf
Hide thumbs
Also See for C5 Series:
- Instruction sheet (15 pages) ,
- Assembly instructions manual (10 pages) ,
- Installation instructions (4 pages)
Table of Contents
Related Manuals for Middle Atlantic Products C5 Series
Summary of Contents for Middle Atlantic Products C5 Series
- Page 1 C5 SERIES Flip-Up Side Shelf THANK YOU Thank you for purchasing the C5 Series Flip-Up Side Shelf. Please read these instructions thoroughly before installing this product. PRODUCT FEATURES • Weight rated to 35 lbs. of maximum capacity. I-00689...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS / INSTRUCTIONS IMPORTAANTES SUR LA SÉCURITÉ WARNING! Middle Atlantic Products, Inc. electrical AVERTISSEMENT! Middle Atlantic Products, Inc. systems conform to and should be properly grounded in électrique systèmes conformes à devraient être mis à la compliance with requirements of the current National terre dans conformité...
- Page 3 REQUIRED TOOLS • #2 Phillips Screwdriver (at least 6” long) • 1/4” Drill Bit • Drill • Hammer INSTALLATION NOTE: Installation of the brackets must be done with the C5 top off. 1. Remove the side panel on the side you wish to install the shelf. Mounting Holes 2.
- Page 4 INSTALLATION (CONTINUED) 5. Remove the plastic tube from both brackets. (FIGURE C) PLASTIC TUBE FIGURE C NOTE: Ensure the brackets are in the full open position prior to installing the shelf. 6. Place the shelf on the brackets. Install shelf using using (8) 10 x 3/4” Phillips pan head wood screws, 4 places per bracket.
- Page 5 WARRANTY Middle Atlantic Products, Inc. (the "Company") warrants the product to be free from defects in material or workmanship under normal use and conditions for a period of (3) three years from the date of shipment by the Company. The Company's entire liability to the purchaser, and the purchaser's (or any other party's) sole and...
