ASSEMBLY
NOTE: For ease of installation, half height
side panel should be installed while desk is
flipped upside down.
1) Screw bracket into the front, bottom insert.
(FIGURE A)
2) Attach side panel to desk by inserting bracket into slot
on bottom of leg. (See FIGURE B)
3) Use provided screws to attach side panel to desk. 1 screw fastens to desktop support,
2 screws fasten through inside of cabinet into side panel insert - 1 on top and 1 on bottom.
(FIGURE C)
Instruction Sheet
LD SERIES
LD-SP-X Side PanelS
HALF HEIGHT
FIGURE A
FIGURE C
LOOSELY INSTALL
FIGURE B
FULL HEIGHT
I-00086
Rev E
