Summary of Contents for Birlea URBAN STUDY DESK
- Page 2 ASSEMBLY INSTRUCTIONS URBAN STUDY DESK IMPORTANT : READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR URBAN STUDY DESK. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. ASSEMBLY: Assembly should be carried out with this item laying flat, not standing upright.
- Page 3 Vendor: S000350 Parts List Hardware List Part Descripion Qty Part Description Top panel Allen key M4 Middle panel JCBC screw M6 x 20mm Bottom panel JCBC screw M6 x 30mm Metal Side ( Left ) JCBC screw M6 x 40mm Metal Side ( Right ) M3.5 x 16mm C.B Screw Metal Center...
- Page 4 Vendor: S000350 Step 2: Attach the Metal Bottom (9) to Metal Center (6) using hardware A and B. Attach the Metal Bottom (9) to Metal Side Left (4) using hardware A and B. Attach the Metal Top Left (7) to Metal Side Left (4) using hardware A and D. DO NOT tighten all the screw.
- Page 5 Ensure the head of any screw used has a diameter greater than the mounting hole and the fixing is safe and secure before use. Birlea Furniture advise you use the wall straps provided to further enhance the safety of this product.
