Periodically check all screws & fixings to ensure they are secure. DO NOT push this product as this will cause damage. Always lift this product with two people to repositions. Keep any sharp objects away from this product . Page of 7 www.birlea.com... - Page 3 Vendor: S000350 Parts List Hardware List ( BOX 1 ) Part Descripion Part Description Middle panel Cam lock Up box top panel Minifix screw Up box side panel ( Left ) Plastic cap Up box side panel ( Right ) M8 x 30mm Wood Dowel Up box back panel M6 x 50mm CSK Cap Wood screw...
- Page 4 Vendor: S000350 Step 1: Prepare these parts for assembly using hardware parts A1, A2, B, D, G, H, I, J, M, N and O1. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Page of 7...
- Page 5 Vendor: S000350 Step 2: Attach up box side panel (3) and (4) to up box top panel (2) using hardware A1 and A2 with a screwdriver (not provided). Attach down box side panel (9) and down (10) to down box top panel (8) using hardware A1 and A2 with a screwdriver (not provided).
- Page 6 Vendor: S000350 Step 5: Attach metal side (16) to metal middle (17) using hardware K and F. DO NOT use any power tools as this may damage the frame and will invalidate any claim. K x 16 Step 6: Attach door panel (6) to up box side panel (3) using hardware D with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 7 Vendor: S000350 Step 7: Attach hardware L1 into up box top panel (2), up box side panel (3), (4) and box bottom panel (7) using hardware L2 with a screwdriver (not provided). Attach hardware L1 into box bottom panel (7), down box top panel (8), down box side panel (9) and (10) using hardware L2 with a screwdriver (not provided).
- Page 8 Ensure the head of any screw used has a diameter greater than the mounting hole and the fixing is safe and secure before use. Birlea Furniture advise you use the wall straps provided to further enhance the safety of this product.
