Summary of Contents for Birlea URBWSURUS
- Page 2 Periodically check all screws & fixings to ensure they are secure. DO NOT push this product as this will cause damage. Always lift this product with two people to repositions. Keep any sharp objects away from this product . Page of 4 www.birlea.com...
- Page 3 Vendor: S000350 Parts List Hardware List Part Descripion Part Description Top/Bottom panel Allen key M4 Large Middle panel JCBC screw M6 x 40mm Small Middle panel M3.5 x 16mm C.B Screw Large Metal Middle 8'' x 1'' PP tape Wall plug Top/Bottom Metal Middle Small Metal Middle M4 x 38mm C.B Screw...
- Page 4 Vendor: S000350 Step 1: Attach Large Metal Middle (4) and Top/Bottom Metal Middle (5) to Large Metal Center (7) and Small Metal Center (8) using hardware A and B. DO NOT use any power tools as this may damage the frame and will invalidate any claim. B x 12 Step 2: Attach Metal Side-L (9) and Metal Side-R (10) to Large Metal Middle (4), Top/Bottom Metal Middle (5) and Small Metal Middle (6) using hardware A and B.
- Page 5 Ensure the head of any screw used has a diameter greater than the mounting hole and the fixing is safe and secure before use. Birlea Furniture advise you use the wall straps provided to further enhance the safety of this product.
