Page 2: Health And Safety
Periodically check all screws & fixings to ensure they are secure. DO NOT push this product as this will cause damage. Always lift this product with two people to repositions. Keep any sharp objects away from this product . Page of 8 www.birlea.com... - Page 3 Vendor: S000350 Parts List Hardware List ( BOX 2 ) Part Descripion Qty Part Description Top panel Cam lock Bottom panel Minifix screw Side panel ( Left ) Plastic cap Side panel ( Right ) M8 x 30mm Wood Dowel Center panel M6 x 50mm CSK Cap Wood screw Back panel...
- Page 4 Vendor: S000350 Step 1: Insert hardware parts A1, A2, B, D and M1 into parts (1), (3), (4), (5) & (7) like the below. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Right face Left face Step 2: Attach back bone (7) to side panel (3) and center panel (5) using hardware A1 and A2...
- Page 5 Vendor: S000350 Step 3: Attach side panel (3), (4) and center panel (5) to top panel (1) using hardware A1 and A2 with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. A3 x 6 Step 4: Insert back panel (6) along the slot.
- Page 6 Vendor: S000350 Step 6: Attach hardware L1 into top panel (1), bottom panel (2), side panel (3) and (4) using hardware L2 with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. L1 x 8 L2 x 8 Step 7: Attach metal middle (16) to bottom panel (2) using hardware J and F.
- Page 7 Vendor: S000350 Step 8: Assemble the drawer components using hardware D, E, G, I and M2. In this step only show one of the drawers. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Smaller drawers Insert Hardware part (G) to the drawer front (up) (8) using hardware part (I) Attach the drawer side (up) (10) to the drawer back (up) (11) and the drawer front (up) (8)
- Page 8 Vendor: S000350 Step 9: Assemble the drawer components using hardware D, E, G, H and M2. In this step only show one of the drawers. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Larger drawers Insert Hardware part (G) to the drawer front (down) (9) using hardware part (H) Attach the drawer side (down) (12) to the drawer back (down) (13) and...
-
Page 9: Additional Information
Ensure the head of any screw used has a diameter greater than the mounting hole and the fixing is safe and secure before use. Birlea Furniture advise you use the wall straps provided to further enhance the safety of this product.
