Page 2: Health And Safety
Periodically check all screws & fixings to ensure they are secure. DO NOT push this product as this will cause damage. Always lift this product with two people to repositions. Keep any sharp objects away from this product . Page of 6 www.birlea.com... - Page 3 Vendor: S000350 Parts List Hardware List Part Descripion Qty Part Description Top panel Cam lock Bottom panel Minifix screw Side panel ( Left ) Plastic cap Side panel ( Right ) M8 x 30mm Wood Dowel Center panel M6 x 50mm CSK Cap Wood screw Middle panel M3.5 x 16mm C.B Screw Drawer front...
- Page 4 Vendor: S000350 Step 1: Prepare these parts for assembly using hardware parts A1, A2, B, D and K1. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 2: Attach the panel (5) and (6) to panel (1) using hardware A1 and A3 with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 5 Vendor: S000350 Step 4: Attach the panel (2) to panel (3), (4), (5) and (6) using hardware C and F. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 5: Attach the Metal Top (11) to panel (2) using hardware I and F. DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 6 Vendor: S000350 Step 7: Fix hardware G onto panel (7) using hardware H with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 8: Assemble the drawer components using hardware D, E and K2. In this step only show one of the drawers.
- Page 7 If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. · Why don't you send us photos of your assembled furniture to info@birlea.com to be shared in our #birleahome feature on instagram. Page...
