Page 2: Health And Safety
Periodically check all screws & fixings to ensure they are secure. DO NOT push this product as this will cause damage. Always lift this product with two people to repositions. Keep any sharp objects away from this product . Page of 9 www.birlea.com... - Page 3 Vendor: S000350 Parts List Hardware List ( BOX 2 ) Part Descripion Part Description Top panel Cam lock Bottom panel Minifix screw Side panel (Left) Plastic cap Side panel ( Right ) M8 x 30mm Wood Dowel Center panel (Left) M6 x 50mm CSK Cap Wood screw Center panel (Right) M3.5 x 16mm C.B Screw...
- Page 4 Vendor: S000350 Step 1: Insert hardware parts A1, A2, B, D, F, G, H, L, M and N1 into part (1),(3),(4),(5),(6),(7),(8),(10),(11),(12),(13) like the below. A1 x 16 A2 x 16 B x 20 Left Face D x 38 G x 7 Right Face H x 14 M x 4...
- Page 5 Vendor: S000350 Step 2: Attach center panel left (5) and center panel right (6) to back bone (8) using hardware A1 and A2 with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. A3 x 4 Page of 9...
- Page 6 Vendor: S000350 Step 3: Attach side panel (3) and side panel (4) to bone panel (7) using hardware A1 and A2 with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. A3 x 4 Step 4: Attach side panel (3), side panel (4), center panel (Left) (5), center panel (right) (6) to top panel (1) using hardware A1 and A2 with a screwdriver (not provided).
- Page 7 Vendor: S000350 Step 6: Attach bottom panel (2) to side panel (3), side panel (4), center panel (left) (5) and center panel (right) (6) using hardware C and F. DO NOT use any power tools as this may damage the frame and will invalidate any claim. C x 8 Step 7: Attach hardware K1 into top panel (1), bottom panel (2), side panel (3) and (4) using hardware K2 with a screwdriver (not provided).
- Page 8 Vendor: S000350 Step 9: Attach metal frame side (17) to side panel (3) and (4) using hardware F and I. Attach metal frame side (17) to metal frame middle (18) using hardware F and J. DO NOT use any power tools as this may damage the frame and will invalidate any claim. I x 4 J x 4 Step 10: Attach door panel (10) to side panel (3) and door panel (11) to side panel (4) using hardware D with a...
- Page 9 Vendor: S000350 Step 11: 1.Attach the drawer side (15) to the drawer back (14) and drawer front (12) using hardware part (E). 2.Slide in the drawer bottom (16) then attach the drawer side (15) using hardware part (E). 3.Attach the hardware part (N2) to the drawer sides (15) using hardware part (D). D x 18 E x 24 ( L/R )
-
Page 10: Additional Information
Ensure the head of any screw used has a diameter greater than the mounting hole and the fixing is safe and secure before use. Birlea Furniture advise you use the hardware P ( 2 pcs ) are provided to further enhance the safety of this product.
